Panasonic PhotoMOS® Relays are MOSFET-enabled Solid State Relays featuring low off-state leakage current and stable on-resistance over the component lifetime.

Results 592

Specifications table for model
Part No.	Type	Package	Contact Arrangement	Load Voltage [ V_L ] (V_L)	Continuous Load Current(I_L)	I/O Isolation Voltage(V_iso)	On Resistance (Typical) (R_on)	LED Operate Current (Maximum)	Off State Leakage Current (Maximum)(I_Leak)	Turn On Time (Maximum)	Output Capacitance (Typical) (C_out)	Ambient Temperature: Operating(T_opr)	Turn Off Time (Maximum)	Terminal Type	Packing Quantity
	Select All GU RF HE GE HF Power CC HS PD	Select All DIP6 DIP8 SOP4 DIP4 SOP6 SSOP SOP8 SIL4 TSON Power-DIP4 SOP16 VSSOP SON WSSOP	Select All 1 Form A 2 Form A 1 Form B 1 Form A 1 Form B 2 Form B 4 Form A	Select All 400 V 60 V 350 V 40 V 200 V 100 V 600 V 250 V 30 V 80 V 25 V 20 V 1,500 V 1000 V 1500 V 1,200 V 50 V	Select All 0.12 A 0.1 A 0.5 A 0.15 A 0.13 A 0.04 A 0.05 A 0.4 A 0.25 A 0.3 A 0.2 A 0.55 A 0.16 A 0.18 A 0.35 A 1.25 A 0.02 A 3.5 A 0.07 A 1 A 0.06 A 0.08 A 0.75 A 0.6 A 0.7 A 1.0A 1.1 A 1.3 A 2.0 A 0.03 A 0.32 A 0.45 A 0.65 A 0.8 A 2.4 A 2.5 A 3.0 A 0.10 A 0.14 A 1.6 A 1.8 A 2.2 A 3.3 A 2 A 0.9 A 10 A 2.0A 2.3 A 2.6 A 2.7 A 3.6 A 4.0 A 4.0A 5 A 6.0A	Select All 1,500 Vrms 5,000 Vrms 2,500 Vrms 200 Vrms 500 Vrms 3,750 Vrms 3,000 Vrms	Select All 30 Ω 26 Ω 11 Ω 18 Ω 0.8 Ω 5.5 Ω 70 Ω 0.83 Ω 1 Ω 20 Ω 23 Ω 9.5 Ω 2.3 Ω 12.4 Ω 10.5 Ω 0.07 Ω 0.033 Ω 0.34 Ω 0.6 Ω 0.74 Ω 52 Ω 0.18 Ω 0.55 Ω 0.85 Ω 1.8 Ω 27 Ω 0.08 Ω 0.2 Ω 2.8 Ω 0.035 Ω 0.11 Ω 0.23 Ω 0.7 Ω 0.75 Ω 2.1 Ω 8.8 Ω 0.09 Ω 0.25 Ω 0.3 Ω 0.37 Ω 10.2 Ω 2.6 Ω 2.7 Ω 23 ohm 25.2 Ω 26 ohm 30 ohm 315 Ω 345 Ω 6.3 Ω 85 Ω 0.04 Ω 0.1 Ω 0.2 ohm 0.75 ohm 0.9 Ω 16 Ω 17 Ω 19 Ω 23.5 Ω 25 Ω 9 Ω 9.5 ohm 0.4 Ω 4 Ω 8 Ω 0.008 Ω 0.015 Ω 0.031 Ω 0.05 Ω 0.066 Ω 0.081 Ω 0.33 Ω 0.52 Ω 0.64 Ω 1.06 Ω 1.23 Ω 2.4 Ω	Select All 3.0 mA 3 mA 5.0 mA 0.5 mA 3 mA (N.C.) (N.O.) 1 mA 1.3 mA 10 mA	Select All 1μA 10 nA 10μA 10nA 1μA 1μA (N.O.), 10μA (N.C.) 1 μA	Select All 0.5 ms 2.0 ms 1.0 ms 5.0 ms 3 ms 2 ms 5 ms 1 ms 0.2 ms 3.0 ms 10 ms 4 ms 0.75 ms 0.1 ms 0.8 ms 10.0ms 4.0 ms (N.O.), 10.0 ms (N.C.) 8 ms 0.3 ms 7.5 ms	Select All 10 pF 1.1 pF 1.0 pF 27 pF 37.5 pF 4.5 pF 5.8 pF 12.5 pF 14 pF 1 pF 1.2 pF 13 pF 13.0 pF 14.5 pF 24 pF 24.5 pF 33 pF 40 pF 16 pF	Select All -40 to +85℃ -40 to +105℃ -40 to +85°C -40 to +185°F -40 to +85°C -40～+85℃ (4 V ≦ V_IN ≦ 6 V) -40～+75℃ (6 V < V_IN ≦ 15 V) -40～+60℃ (15 V < V_IN ≦ 30 V) -40 to +125℃ -40 to +125C	Select All 0.2 ms 1.0 ms 0.5 ms 1 ms 3.0 ms 1.5 ms 2.0 ms 3 ms 0.1 ms	Select All Surface-mount terminal Through hole terminal	Select All Tube packing style Tape and reel packing style (X) Tape and reel packing style (Z) Tape and reel packing style (Y) Tape and reel packing style (W) Tape and reel packing style (1Y) Tape and reel packing style (1X)
APV1111GVYMore Info	–	SSOP	–	–	–	1,500 Vrms	–	–	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tape and reel packing style (Y)
APV1121SMore Info	–	SOP4	–	–	–	2,500 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tube packing style
APV1121SXMore Info	–	SOP4	–	–	–	2,500 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tape and reel packing style (X)
APV1121SZMore Info	–	SOP4	–	–	–	2,500 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tape and reel packing style (Z)
APV1122More Info	–	DIP6	–	–	–	5,000 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Through hole terminal	Tube packing style
APV1122AMore Info	–	DIP6	–	–	–	5,000 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tube packing style
APV1122AXMore Info	–	DIP6	–	–	–	5,000 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tape and reel packing style (X)
APV1122AZMore Info	–	DIP6	–	–	–	5,000 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tape and reel packing style (Z)
APV2111V1YMore Info	–	SSOP	–	–	–	1,500 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tape and reel packing style (1Y)
APV2111VWMore Info	–	SSOP	–	–	–	1,500 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tape and reel packing style (W)
APV2111VYMore Info	–	SSOP	–	–	–	1,500 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tape and reel packing style (Y)
APV2121SMore Info	–	SOP4	–	–	–	2,500 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tube packing style
APV2121SXMore Info	–	SOP4	–	–	–	2,500 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tape and reel packing style (X)
APV2121SZMore Info	–	SOP4	–	–	–	2,500 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tape and reel packing style (Z)
APV3111GVYMore Info	–	SSOP	–	–	–	1,500 Vrms	–	–	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tape and reel packing style (Y)
AQS221FN2SMore Info	RF	SOP16	4 Form A	40 V	0.06 A	500 Vrms	9.5 ohm	–	10 nA	0.5 ms	1 pF	-40 to +85°C	0.2 ms	Surface-mount terminal	Tube packing style
AQS221FN2SXMore Info	RF	SOP16	4 Form A	40 V	0.06 A	500 Vrms	9.5 ohm	–	10 nA	0.5 ms	1 pF	-40 to +85°C	0.2 ms	Surface-mount terminal	Tape and reel packing style (X)
AQS221FN2SZMore Info	RF	SOP16	4 Form A	40 V	0.06 A	500 Vrms	9.5 ohm	–	10 nA	0.5 ms	1 pF	-40 to +85°C	0.2 ms	Surface-mount terminal	Tape and reel packing style (Z)
AQS221FR2SMore Info	RF	SOP16	4 Form A	40 V	0.16 A	500 Vrms	0.75 ohm	–	10 nA	0.5 ms	12.5 pF	-40 to +85°C	0.2 ms	Surface-mount terminal	Tube packing style
AQS221FR2SXMore Info	RF	SOP16	4 Form A	40 V	0.16 A	500 Vrms	0.75 ohm	–	10 nA	0.5 ms	12.5 pF	-40 to +85°C	0.2 ms	Surface-mount terminal	Tape and reel packing style (X)
AQS221FR2SZMore Info	RF	SOP16	4 Form A	40 V	0.16 A	500 Vrms	0.75 ohm	–	10 nA	0.5 ms	12.5 pF	-40 to +85°C	0.2 ms	Surface-mount terminal	Tape and reel packing style (Z)
AQS221N2SMore Info	RF	SOP16	4 Form A	40 V	0.06 A	500 Vrms	9.5 Ω	3.0 mA	10 nA	0.2 ms	1.0 pF	-40 to +85℃	0.2 ms	Surface-mount terminal	Tube packing style
AQS221N2SXMore Info	RF	SOP16	4 Form A	40 V	0.06 A	500 Vrms	9.5 Ω	3.0 mA	10 nA	0.2 ms	1.0 pF	-40 to +85℃	0.2 ms	Surface-mount terminal	Tape and reel packing style (X)
AQS221N2SZMore Info	RF	SOP16	4 Form A	40 V	0.06 A	500 Vrms	9.5 Ω	3.0 mA	10 nA	0.2 ms	1.0 pF	-40 to +85℃	0.2 ms	Surface-mount terminal	Tape and reel packing style (Z)
AQS221R2SMore Info	RF	SOP16	4 Form A	40 V	0.16 A	500 Vrms	0.8 Ω	3.0 mA	10 nA	0.5 ms	13.0 pF	-40 to +85℃	0.2 ms	Surface-mount terminal	Tube packing style
AQS221R2SXMore Info	RF	SOP16	4 Form A	40 V	0.16 A	500 Vrms	0.8 Ω	3.0 mA	10 nA	0.5 ms	13.0 pF	-40 to +85℃	0.2 ms	Surface-mount terminal	Tape and reel packing style (X)
AQS221R2SZMore Info	RF	SOP16	4 Form A	40 V	0.16 A	500 Vrms	0.8 Ω	3.0 mA	10 nA	0.5 ms	13.0 pF	-40 to +85℃	0.2 ms	Surface-mount terminal	Tape and reel packing style (Z)
AQS225R2SMore Info	RF	SOP16	4 Form A	80 V	0.07 A	1,500 Vrms	10.5 Ω	3.0 mA	10 nA	0.3 ms	4.5 pF	-40 to +85℃	0.2 ms	Surface-mount terminal	Tube packing style
AQS225R2SXMore Info	RF	SOP16	4 Form A	80 V	0.07 A	1,500 Vrms	10.5 Ω	3.0 mA	10 nA	0.3 ms	4.5 pF	-40 to +85℃	0.2 ms	Surface-mount terminal	Tape and reel packing style (X)
AQS225R2SZMore Info	RF	SOP16	4 Form A	80 V	0.07 A	1,500 Vrms	10.5 Ω	3.0 mA	10 nA	0.3 ms	4.5 pF	-40 to +85℃	0.2 ms	Surface-mount terminal	Tape and reel packing style (Z)
AQV101More Info	HF	DIP6	1 Form A	40 V	0.7 A	1,500 Vrms	0.3 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Through hole terminal	Tube packing style
AQV101AMore Info	HF	DIP6	1 Form A	40 V	0.7 A	1,500 Vrms	0.3 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tube packing style
AQV101AXMore Info	HF	DIP6	1 Form A	40 V	0.7 A	1,500 Vrms	0.3 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tape and reel packing style (X)
AQV101AZMore Info	HF	DIP6	1 Form A	40 V	0.7 A	1,500 Vrms	0.3 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tape and reel packing style (Z)
AQV102More Info	HF	DIP6	1 Form A	60 V	0.6 A	1,500 Vrms	0.37 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Through hole terminal	Tube packing style
AQV102AMore Info	HF	DIP6	1 Form A	60 V	0.6 A	1,500 Vrms	0.37 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tube packing style
AQV102AXMore Info	HF	DIP6	1 Form A	60 V	0.6 A	1,500 Vrms	0.37 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tape and reel packing style (X)
AQV102AZMore Info	HF	DIP6	1 Form A	60 V	0.6 A	1,500 Vrms	0.37 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tape and reel packing style (Z)
AQV103More Info	HF	DIP6	1 Form A	250 V	0.3 A	1,500 Vrms	2.7 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Through hole terminal	Tube packing style
AQV103AMore Info	HF	DIP6	1 Form A	250 V	0.3 A	1,500 Vrms	2.7 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tube packing style
AQV103AXMore Info	HF	DIP6	1 Form A	250 V	0.3 A	1,500 Vrms	2.7 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tape and reel packing style (X)
AQV103AZMore Info	HF	DIP6	1 Form A	250 V	0.3 A	1,500 Vrms	2.7 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tape and reel packing style (Z)
AQV104More Info	HF	DIP6	1 Form A	400 V	0.18 A	1,500 Vrms	6.3 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Through hole terminal	Tube packing style
AQV104AMore Info	HF	DIP6	1 Form A	400 V	0.18 A	1,500 Vrms	6.3 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tube packing style
AQV104AXMore Info	HF	DIP6	1 Form A	400 V	0.18 A	1,500 Vrms	6.3 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tape and reel packing style (X)
AQV104AZMore Info	HF	DIP6	1 Form A	400 V	0.18 A	1,500 Vrms	6.3 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tape and reel packing style (Z)
AQV112KLMore Info	GU	DIP6	1 Form A	60 V	0.5 A	1,500 Vrms	0.55 Ω	10 mA	1μA	5.0 ms	–	-40 to +85℃	1.0 ms	Through hole terminal	Tube packing style
AQV112KLAMore Info	GU	DIP6	1 Form A	60 V	0.5 A	1,500 Vrms	0.55 Ω	10 mA	1μA	5.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tube packing style
AQV112KLAXMore Info	GU	DIP6	1 Form A	60 V	0.5 A	1,500 Vrms	0.55 Ω	10 mA	1μA	5.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tape and reel packing style (X)
AQV112KLAZMore Info	GU	DIP6	1 Form A	60 V	0.5 A	1,500 Vrms	0.55 Ω	10 mA	1μA	5.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tape and reel packing style (Z)

Specifications table for model
Part No.	Type	Package	Contact Arrangement	Load Voltage [ V_L ] (V_L)	Continuous Load Current(I_L)	I/O Isolation Voltage(V_iso)	On Resistance (Typical) (R_on)	LED Operate Current (Maximum)	Off State Leakage Current (Maximum)(I_Leak)	Turn On Time (Maximum)	Output Capacitance (Typical) (C_out)	Ambient Temperature: Operating(T_opr)	Turn Off Time (Maximum)	Terminal Type	Packing Quantity

APV1111GVYMore Info	–	SSOP	–	–	–	1,500 Vrms	–	–	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tape and reel packing style (Y)
APV1121SMore Info	–	SOP4	–	–	–	2,500 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tube packing style
APV1121SXMore Info	–	SOP4	–	–	–	2,500 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tape and reel packing style (X)
APV1121SZMore Info	–	SOP4	–	–	–	2,500 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tape and reel packing style (Z)
APV1122More Info	–	DIP6	–	–	–	5,000 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Through hole terminal	Tube packing style
APV1122AMore Info	–	DIP6	–	–	–	5,000 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tube packing style
APV1122AXMore Info	–	DIP6	–	–	–	5,000 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tape and reel packing style (X)
APV1122AZMore Info	–	DIP6	–	–	–	5,000 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tape and reel packing style (Z)
APV2111V1YMore Info	–	SSOP	–	–	–	1,500 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tape and reel packing style (1Y)
APV2111VWMore Info	–	SSOP	–	–	–	1,500 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tape and reel packing style (W)
APV2111VYMore Info	–	SSOP	–	–	–	1,500 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tape and reel packing style (Y)
APV2121SMore Info	–	SOP4	–	–	–	2,500 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tube packing style
APV2121SXMore Info	–	SOP4	–	–	–	2,500 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tape and reel packing style (X)
APV2121SZMore Info	–	SOP4	–	–	–	2,500 Vrms	–	3.0 mA	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tape and reel packing style (Z)
APV3111GVYMore Info	–	SSOP	–	–	–	1,500 Vrms	–	–	–	–	–	-40 to +85℃	–	Surface-mount terminal	Tape and reel packing style (Y)
AQS221FN2SMore Info	RF	SOP16	4 Form A	40 V	0.06 A	500 Vrms	9.5 ohm	–	10 nA	0.5 ms	1 pF	-40 to +85°C	0.2 ms	Surface-mount terminal	Tube packing style
AQS221FN2SXMore Info	RF	SOP16	4 Form A	40 V	0.06 A	500 Vrms	9.5 ohm	–	10 nA	0.5 ms	1 pF	-40 to +85°C	0.2 ms	Surface-mount terminal	Tape and reel packing style (X)
AQS221FN2SZMore Info	RF	SOP16	4 Form A	40 V	0.06 A	500 Vrms	9.5 ohm	–	10 nA	0.5 ms	1 pF	-40 to +85°C	0.2 ms	Surface-mount terminal	Tape and reel packing style (Z)
AQS221FR2SMore Info	RF	SOP16	4 Form A	40 V	0.16 A	500 Vrms	0.75 ohm	–	10 nA	0.5 ms	12.5 pF	-40 to +85°C	0.2 ms	Surface-mount terminal	Tube packing style
AQS221FR2SXMore Info	RF	SOP16	4 Form A	40 V	0.16 A	500 Vrms	0.75 ohm	–	10 nA	0.5 ms	12.5 pF	-40 to +85°C	0.2 ms	Surface-mount terminal	Tape and reel packing style (X)
AQS221FR2SZMore Info	RF	SOP16	4 Form A	40 V	0.16 A	500 Vrms	0.75 ohm	–	10 nA	0.5 ms	12.5 pF	-40 to +85°C	0.2 ms	Surface-mount terminal	Tape and reel packing style (Z)
AQS221N2SMore Info	RF	SOP16	4 Form A	40 V	0.06 A	500 Vrms	9.5 Ω	3.0 mA	10 nA	0.2 ms	1.0 pF	-40 to +85℃	0.2 ms	Surface-mount terminal	Tube packing style
AQS221N2SXMore Info	RF	SOP16	4 Form A	40 V	0.06 A	500 Vrms	9.5 Ω	3.0 mA	10 nA	0.2 ms	1.0 pF	-40 to +85℃	0.2 ms	Surface-mount terminal	Tape and reel packing style (X)
AQS221N2SZMore Info	RF	SOP16	4 Form A	40 V	0.06 A	500 Vrms	9.5 Ω	3.0 mA	10 nA	0.2 ms	1.0 pF	-40 to +85℃	0.2 ms	Surface-mount terminal	Tape and reel packing style (Z)
AQS221R2SMore Info	RF	SOP16	4 Form A	40 V	0.16 A	500 Vrms	0.8 Ω	3.0 mA	10 nA	0.5 ms	13.0 pF	-40 to +85℃	0.2 ms	Surface-mount terminal	Tube packing style
AQS221R2SXMore Info	RF	SOP16	4 Form A	40 V	0.16 A	500 Vrms	0.8 Ω	3.0 mA	10 nA	0.5 ms	13.0 pF	-40 to +85℃	0.2 ms	Surface-mount terminal	Tape and reel packing style (X)
AQS221R2SZMore Info	RF	SOP16	4 Form A	40 V	0.16 A	500 Vrms	0.8 Ω	3.0 mA	10 nA	0.5 ms	13.0 pF	-40 to +85℃	0.2 ms	Surface-mount terminal	Tape and reel packing style (Z)
AQS225R2SMore Info	RF	SOP16	4 Form A	80 V	0.07 A	1,500 Vrms	10.5 Ω	3.0 mA	10 nA	0.3 ms	4.5 pF	-40 to +85℃	0.2 ms	Surface-mount terminal	Tube packing style
AQS225R2SXMore Info	RF	SOP16	4 Form A	80 V	0.07 A	1,500 Vrms	10.5 Ω	3.0 mA	10 nA	0.3 ms	4.5 pF	-40 to +85℃	0.2 ms	Surface-mount terminal	Tape and reel packing style (X)
AQS225R2SZMore Info	RF	SOP16	4 Form A	80 V	0.07 A	1,500 Vrms	10.5 Ω	3.0 mA	10 nA	0.3 ms	4.5 pF	-40 to +85℃	0.2 ms	Surface-mount terminal	Tape and reel packing style (Z)
AQV101More Info	HF	DIP6	1 Form A	40 V	0.7 A	1,500 Vrms	0.3 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Through hole terminal	Tube packing style
AQV101AMore Info	HF	DIP6	1 Form A	40 V	0.7 A	1,500 Vrms	0.3 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tube packing style
AQV101AXMore Info	HF	DIP6	1 Form A	40 V	0.7 A	1,500 Vrms	0.3 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tape and reel packing style (X)
AQV101AZMore Info	HF	DIP6	1 Form A	40 V	0.7 A	1,500 Vrms	0.3 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tape and reel packing style (Z)
AQV102More Info	HF	DIP6	1 Form A	60 V	0.6 A	1,500 Vrms	0.37 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Through hole terminal	Tube packing style
AQV102AMore Info	HF	DIP6	1 Form A	60 V	0.6 A	1,500 Vrms	0.37 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tube packing style
AQV102AXMore Info	HF	DIP6	1 Form A	60 V	0.6 A	1,500 Vrms	0.37 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tape and reel packing style (X)
AQV102AZMore Info	HF	DIP6	1 Form A	60 V	0.6 A	1,500 Vrms	0.37 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tape and reel packing style (Z)
AQV103More Info	HF	DIP6	1 Form A	250 V	0.3 A	1,500 Vrms	2.7 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Through hole terminal	Tube packing style
AQV103AMore Info	HF	DIP6	1 Form A	250 V	0.3 A	1,500 Vrms	2.7 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tube packing style
AQV103AXMore Info	HF	DIP6	1 Form A	250 V	0.3 A	1,500 Vrms	2.7 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tape and reel packing style (X)
AQV103AZMore Info	HF	DIP6	1 Form A	250 V	0.3 A	1,500 Vrms	2.7 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tape and reel packing style (Z)
AQV104More Info	HF	DIP6	1 Form A	400 V	0.18 A	1,500 Vrms	6.3 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Through hole terminal	Tube packing style
AQV104AMore Info	HF	DIP6	1 Form A	400 V	0.18 A	1,500 Vrms	6.3 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tube packing style
AQV104AXMore Info	HF	DIP6	1 Form A	400 V	0.18 A	1,500 Vrms	6.3 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tape and reel packing style (X)
AQV104AZMore Info	HF	DIP6	1 Form A	400 V	0.18 A	1,500 Vrms	6.3 Ω	5.0 mA	1μA	1.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tape and reel packing style (Z)
AQV112KLMore Info	GU	DIP6	1 Form A	60 V	0.5 A	1,500 Vrms	0.55 Ω	10 mA	1μA	5.0 ms	–	-40 to +85℃	1.0 ms	Through hole terminal	Tube packing style
AQV112KLAMore Info	GU	DIP6	1 Form A	60 V	0.5 A	1,500 Vrms	0.55 Ω	10 mA	1μA	5.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tube packing style
AQV112KLAXMore Info	GU	DIP6	1 Form A	60 V	0.5 A	1,500 Vrms	0.55 Ω	10 mA	1μA	5.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tape and reel packing style (X)
AQV112KLAZMore Info	GU	DIP6	1 Form A	60 V	0.5 A	1,500 Vrms	0.55 Ω	10 mA	1μA	5.0 ms	–	-40 to +85℃	1.0 ms	Surface-mount terminal	Tape and reel packing style (Z)
