ECPU1C684MA5 137520 in stock

Specification

Specifications table for model ECPU1C684MA5
ItemPerformance characteristics
Body TypeSurface mount type
AC Or DCDC
Rated Voltage (V)16
Temperature Range (°C)-40 to 85
Capacitance (microF)0.68
Capacitance (µF)0.68
Capacitance Tolerance (%)-20 to 20
Dielectric MaterialAcrylic resin
KindFilm chip capacitor
Size code (mm (inch))3216 (1206)
Size Code (mm(inch))3216 (1206)
Body Length (mm)3.2
Width (mm)1.6
Height (mm)1.4
Shape of Lead Wire Non lead wire
Packaging8.0W180A emboss taping (reel packing)
Minimum Packaging Quantity 2000
Weight (Typ.) (g)0.016

Stock Check

Stock check for product ECPU1C684MA5
DistributorQuantityInventory Date
Digi-Key Electronics
United States
Tel. 1-800-344-4539
4690107/04/2020
Digi-Key Electronics
United States
Tel. 1-800-344-4539
4600007/04/2020
Future Electronics
Canada
Tel. 1-514-694-7710
2000007/03/2020
TTI Inc
United States
Tel. 1-800-225-5884
1400007/03/2020
Mouser Electronics
United States
Tel. 800-346-6873
614907/02/2020
Newark, An Avnet Company
United States
Tel. 1-800-4-NEWARK
200007/04/2020
TTI Inc
United States
Tel. 1-800-225-5884
143007/03/2020
e-Sonic
Canada
Tel. 1-800-567-6642
68007/04/2020
Master Electronics
United States
Tel. 888-473-5297
18007/04/2020
Onlinecomponents
United States
Tel. 888-906-8217
18007/04/2020
