|Body Type||Surface mount type (vertical mount style)|
|Rated Voltage (V)||10|
|Capacitance Tolerance (%)||-20 to 20|
|Tangent Of Loss Angle (Max.)||0.28|
|Leakage Current (Max.) (μA)||470|
|Leakage Current (Max) (micro A)||470|
|Operating Temperature Range (°C)||-55 to 105|
|Body Diameter (mm)||16|
|Body Length (mm)||16.5|
|Rated Ripple Current (Freq.) (Hz)||120|
|Rated Ripple Current (mA)||1280|
|Rated Ripple Current (Unit)||ｍArms|
|Forming & Packaging Feature||Embossed carrier taping (reel packing)|
|Appearance||Sheathless (metal case)|
|Minimum Packaging Quantity (pieces)||125|
|Minimum packaging quantity (piece)||125|
|Minimum Packaging Quantity (PCS.)||125|
|Weight (Typ.) (g)||5.2|
