Common Mode Noise Filter

Common Mode Noise Filters are devices used to filter out undesirable frequencies in a signal. Common Mode Noise Filters are used to insure the integrity of the USB or HDMI signal to meet the standard required for those applications.

Panasonic offers Common Mode Noise Filters with benefits such as:

  • Wide range lineup(Small size or Array type) for common mode noise suppression.
  • Good signal integrity for high bit rate data transmission.
  • Wide pass-band for differential signal.
  • Simple multi-layer structure.
  • Good durability and mounting reliability.

Series List

Results 22
Series table for lineup Common Mode Noise Filter
Series/TypeDatasheetFeaturesSize (mm) (in)DC Resistance (Ω)Reach (Report of Confirmation) Impedance [Common Mode] (Ω)RoHS (Compliance Certificate)Rated Voltage [DC] (V)Rated Current [DC] (mA)
High attenuation
(for Gbps)
0202
3.0
SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)
20
RoHS compliant (Please refer to the Related Information.)
10
100
High speed Differential transmission
(for Gbps)
(USB3.0, HDMI2.0)
0202
2.0, 2.7
SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)
12, 35
RoHS compliant (Please refer to the Related Information.)
5
100
High speed Differential transmission
(for Mbps)
0202
2.4, 3.0
SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)
60, 90
RoHS compliant (Please refer to the Related Information.)
5
100
High attenuation
(for Mbps)
0202
2.7, 3.0
SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)
65, 90
RoHS compliant (Please refer to the Related Information.)
10
100
High speed Differential transmission
(for Gbps)
(USB3.0, HDMI2.0)
0302
1.0, 1.5
SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)
12, 35
RoHS compliant (Please refer to the Related Information.)
5
100
High speed Differential transmission
(for Mbps/Gbps)
0302
2.0 to 3.8
SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)
12 to 120
RoHS compliant (Please refer to the Related Information.)
5
100, 130
High attenuation
(for Mbps)
0302
2.3, 3.3
SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)
50, 90
RoHS compliant (Please refer to the Related Information.)
5
100
Signal Harmonics Relaxation
(for Mbps)
0302
3.0, 4.0
SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)
28, 40
RoHS compliant (Please refer to the Related Information.)
5
100
High attenuation
(for MIPI C-PHY)
0403
3.0, 4.0
SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)
25, 35
RoHS compliant (Please refer to the Related Information.)
5
100
High speed Differential transmission
(for Gbps)
(USB3.0, HDMI2.0)
0504
1.5, 2.5
SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)
50, 90
RoHS compliant (Please refer to the Related Information.)
5
130, 160
