Specifications
| Item | Performance characteristics |
|---|---|
| Size [L×W] (EIA) (mm) | 1.6×0.8 (EIA:0603) |
| Rated Current (A) | 4 |
| Internal R [at 25℃ max.] (mΩ) | 22 |
| Fusing Current/Fusing Time [at 25℃] | Rated Current ×100 % / 4 hours min. Rated Current ×200 % / 5 seconds max. Rated Current ×300 % / 0.2 seconds max. |
| Interrupting Rating (A) | 50 |
| Rated Voltage (Open Circuit Voltage) [DC] (V) | 32 |
| Temperature Range (°C) | -40 to +125 |
| Packing Quantity | Punched Carrier Taping, 4 mm pitch |
| Weight (Typ.) (mg) | 2.2 |
