Specifications
| Item | Performance characteristics |
|---|---|
| Transmission Specifications | 1 channel-Bi-direction |
| Receptacle/Plug | Integrated cable and plug |
| Cable Length | 220mm |
| Packing Quantity | 40 pieces |
| Type | BOARD-TO-OPTICAL FIBER |
| Applications | Measuring equipment, Image processing instrument, Industrial robots, Printer, Medical equipment and other high speed transmission, Noise reduction, Electrical isolation applications |
| Transmission Rate | 20 Mbps to 8 Gbps/ch |
| Mated Height (mm) | 6.5 |
| Body Length (mm) | 12.7 |
| Short Width | 9.1 |
| Note) Dimension | The mated height, body length, and short width dimensions above are the dimensions of the plug. Please refer to the dimension drawing for the dimensions of the Duplex-LC connector. |
| Supply Voltage | 3.3V (Typical) |
| Power Consumption | 115mW (Max.) |
| Ambient Temperature | 0 ℃ to +70℃ |
| Piece Type | etc. |
| Short width (mm) | 9.1 |
Stock check
AYG4V52285
