Specifications
Item | Performance characteristics |
---|---|
Size [L×W] (mm) | 12.6×13.2 |
Height (mm) | 8 |
Inductance (μH) | 0.33 |
DC Resistance [Typ.] (at 20℃) (mΩ) | 0.7 |
DC Resistance [Max.] (at 20℃) (mΩ) | 0.77 |
Rated Current [Typ.] (ΔT=40K, FR4, t=1.6 mm, Four-layer PWB) (A) | 44.4 |
Rated Current [Typ.] (ΔT=40K, High heat dissipation PWB) (A) | 53.5 |
Rated Current [Typ.] (ΔL=–30%) (A) | 84.5 |
Weight (Typ.) (g) | 7.3 |
AEC-Q200 compliant | AEC-Q200 compliant |
Stock check
ETQP8MR33JFA
