Specifications
| Item | Performance characteristics |
|---|---|
| Operating Function | Single side stable |
| Rated Coil Voltage | 6 V DC |
| Contact Arrangement | 1 Form A |
| Accessories | Sockets are available. |
| Protective Construction | Sealed |
| Terminal Type | PC board terminal |
| Rated Operating Power | 200 mW |
| Pick-Up Voltage | 70%V or less of rated coil voltage (Initial) |
| Drop-Out Voltage | 10%V or more of rated coil voltage (Initial) |
| Max. Switching Voltage | 250 V AC, 125 V DC (0.2 A) |
| Max. Switching Current | 10 A (AC, DC) |
| Min. Switching Load (Reference Value) | 10 mA 5 V DC |
| Contact Material | Au-flashed AgSnO2 type |
| Mechanical Life | Min. 50x106 ope. (switching frequency: at 300 times/min) |
| Electrical Life | Min. 1x105 |
| Dielectric Strength (Initial): Between Open Contacts | 1,000 Vrms for 1 min (detection current: 10 mA) |
| Dielectric Strength (Initial): Between Contact and Coil | 4,000 Vrms for 1 min (detection current: 10 mA) |
| Ambient Temperature | Ambient temperature: –40 to +70°C Humidity: 5 to 85% R.H. (Not freezing and condensing at low temperature) |
| Insulation Distance | [Between input and output] 6 mm |
| Packing Quantity | Carton |
| Packing Quantity; Inner Carton (Pcs.) | 50 |
| Packing Quantity; Outer Carton (Pcs.) | 500 |
| Operate Voltage (@20oC) | Max. 70% V of rated coil voltage (Initial) |
| Release Voltage (at20°C) | Min. 10% V of rated coil voltage (Initial) |
| Rated Operating Current [±10%] (at 20°C) | 33.3 mA |
| Resistance [±10%] (at 20°C) | 180 Ω |
| Max. Allowable Voltage (at 20°C 68°F) | 130% V of rated coil voltage |
| Contact Resistance (Initial) | Max. 30 mΩ (by voltage drop 6 V DC 1 A) |
| Contact Rating (Resistive Load) | 10 A 250 V AC, 10 A 30 V DC |
| Insulation Resistance (Initial) | Min. 1,000 MΩ (at 500 V DC, Measured portion is the same as the case of dielectric strength.) |
| Surge Withstand Voltage (Initial): Between Contact and Coil | 10,000 V |
| Operate Time (Initial) (At 20oC) | Max. 10 ms at rated coil voltage (without bounce) |
| Release Time (Initial) (at 20°C) | Max. 8 ms at rated coil voltage (without bounce, without diode) |
| Hock Resistance (Functional) | 98 m/s2 (half-sine shock pulse: 11 ms, detection time: 10 μs) |
| Hock Resistance (Destructive) | 980 m/s2 (half-sine shock pulse: 6 ms) |
| Vibration Resistance (Functional) | 10 to 55 Hz (at double amplitude of 1.5 mm, detection time: 10 μs) |
| Vibration Resistance (Destructive) | 10 to 55 Hz (at double amplitude of 3 mm) |
| Weight (Typ.) | Approx. 6 g |
| Conditions | Ambient temperature: -40 to +70℃ Humidity: 5 to 85% RH (Avoid icing and condensation) |
| Resistive Load | [switching frequency: 20 times/min] Min. 100x103 ope. 10 A 250 V AC Min. 100x103 ope. 10 A 30 V DC |
| Max. Switching Power (Resistive Load) | 2,500 VA, 300 W |
Stock check
ADY10006
