Specifications
| Item | Performance characteristics |
|---|---|
| Coil Voltage | 48 V DC |
| Contact Arrangement | 5 Form A 1 Form B |
| Function | With LED indication |
| Packing Quantity; Inner Carton (Pcs.) | 50pcs. |
| Accessories | Sockets and terminal sockets are available. |
| Protective Construction | Flux-resistant |
| Terminal Type | PC board type |
| Rated operating power | 500mW |
| Pick-Up Voltage | 75%V or less of Nominal coil voltage (Initial) |
| Drop-Out Voltage | 10%V or more of Nominal coil voltage (Initial) |
| Max. Switching Voltage | 250V AC/30V DC |
| Max. Switching Current | 6A AC/6A DC |
| Minimum (For Reference) | 1mA 5V DC |
| Contact Material | Au-flashed AgSnO2 type |
| Expected Life: Mechanical | 1x10^7 |
| Expected Life: Electrical | 1x10^5 |
| Breakdown Voltage (Contact-Contact) (Initial) | 1500Vrms |
| Breakdown Voltage (Initial) : Between Contact And Coil | 4000Vrms |
| Ambient Temperature | -40deg to +85deg |
| Operating Function | Single side stable |
| Packing Quantity; Outer Carton (Pcs.) | 200pcs. |
Stock check
SFS5-L-DC48V
