Specifications
| Item | Performance characteristics |
|---|---|
| Lock Travel | 2.5 mm |
| Full Travel | 3.5 mm |
| Operating Mode | Non-lock |
| Switching Mode | Non-shorting |
| Operating Force | 3.5 N ±1.5 N |
| Mounting Type | Dip type |
| Terminal Type | Straight terminal |
| Rating | 50 µA 3 V DC to 0.2 A 14 V DC (Resistive load) |
| Temperature Range | -10°C～+70°C (Standard) -40°C～+85°C (Automotive) |
| Heat Resistance | +70°C for 96 hours (Standard) +85°C for 96 hours (Automotive) |
| Low Temperature Resistance | -10°C for 96 hours (Standard) -40°C for 96 hours (Automotive) |
| Non-Loaded Life (For Consumer Products) | 10,000 cycles (Voltage drop; 0.2 V max.) |
| Humidity Resistance | +40 °C, 90 % to 95 % RH for 96 hours |
| Loaded Life (For Consumer Products) | 10,000 cycles (Voltage drop; 0.2 V max.) |
| Non-Loaded Life (For Automotive Use) | 30,000 cycles (Voltage drop; 0.2 V max.) |
| External Dimensions (WxDxH) | 10.9 x 10 x 20.5 mm |
| Loaded Life (For Automotive Use) | 30,000 cycles (Voltage drop; 0.2 V max.) |
| Mounting Height (mm) (mm) | 12.5 mm |
| Lever Height | 20.5 mm |
| Poles and Throws | 2-poles 2-throws |
| Packaging | Tray Pack |
| Minimum Quantity/Packing Unit | 50 pcs. |
| Quantity/Carton | 2,000 pcs. |
