| Full Travel | 2.5 mm |
| Operating Mode | Non-lock |
| Operating Force | 4.0 N ±1.5 N |
| Mounting Type | Dip type |
| Terminal Type | Formed terminal |
| Rating | 0.01 A 5 V DC to 0.1 A 14 V DC (Resistive load) |
| Temperature Range | -40°C to +85°C (Automotive) |
| Heat Resistance | +85°C for 96 hours (Automotive) |
| Low Temperature Resistance | -40°C for 96 hours (Automotive) |
| Humidity Resistance | +40 °C, 90 % to 95 % RH for 96 hours |
| Non-Loaded Life (For Automotive Use) | 30,000 cycles (Voltage drop; 0.2 V max.) |
| Loaded Life (For Automotive Use) | 30,000 cycles (Voltage drop; 0.2 V max.) |
| External Dimensions (WxDxH) | 7.8 x 7.9 x 12.5 mm |
| Mounting Height (mm) (mm) | 8.9 mm |
| Lever Height | 12.5 mm |
| Poles and Throws | 1-pole 1-throw |
| Packaging | Polyethylene Bag (Bulk) |
| Minimum Quantity/Packing Unit | 60 pcs. |
| Quantity/Carton | 1,200 pcs. |
| Vehicle Compatible | Available |
