PGS Graphite Sheet, SSM

Panasonic Semi-Sealing Material (SSM) Layer is an elastomer layer that helps to facilitate the spread of heat generated by a PC board. Because it is compressible, this SSM layer fills the voids that are inherently present in any circuit board for greater contact with the heat source(s). Pyrolytic Graphite Sheet (PGS) can be ordered in 10 μm, 17 μm, 40 μm, and 50 μm thicknesses for expanded application coverage. This option is ideal for applications where both electrical isolation and thermal management are required.

Features:

  • Lightweight
  • Mechanically Flexible
  • Stong Shielding Characteristics
  • Compressible (SSM)

Benefits:

  • 1/5 the Weight of Copper and 1/2 the Weight of Aluminum
  • Can Be Mounted to Curved Surface or Act as a Heat Pipe
  • Ideal for Electrical and Magnetic Field Suppression up to 1000MHzs
  • Conforms to the Shape of Components for Lower Thermal Resistance

Part Number List

Results 108
Models table for series PGS Graphite Sheet, SSM
Part No.DatasheetSize (mm) (mm)Thickness (μm)Thermal Conductivity (W/(m・K))Thermal conductivity (W/m·K)StyleElectrical CharacteristicsWithstand Temperature (°C)Dielectric Voltage (AC) (V/mm)
115×180
PGS 50
Adhesive tape 10
1300
1300
Adhesive Type
Non-insulated
100
115×180
PGS 50
Adhesive tape 30
1300
1300
Adhesive Type
Non-insulated
100
90×115
Elastomer 3.0
PGS 25
PET 10
1.6
1.6
Insulation
17k
90×115
Elastomer 1.0
PGS 25
PET 10
1.6
1.6
Insulation
17k
180×230
PGS 70
1000
1000
PGS Only
Non-insulated
400
115×180
PGS 40
1350
1350
PGS Only
Non-insulated
400
90×115
Elastomer 0.5
PGS 25
PET 10
1.6
1.6
Insulation
17k
90×115
Elastomer 2.0
PGS 70
PET 10
1.6
1.6
Insulation
17k
115×180
PSG 25
Adhesive tape 6
1600
1600
Adhesive Type
Non-insulated
100
115×180
PSG 25
Adhesive tape 30
1600
1600
Adhesive Type
Non-insulated
100
