PAN1780AT Series Bluetooth® 5.0 Low Energy Module With AT Command Set

Panasonic’s New Bluetooth 5.0 Low Energy RF Module Based On The Nordic nRF52840 Single-Chip Controller With Integrated BlueRadios nBlue™ Bluetooth AT.s LE Command Set

Introducing Panasonic’s NEW PAN1780AT Series RF Module! The PAN1780AT Series RF Module is Panasonic’s Bluetooth 5 Low Energy (LE) RF Module based on the Nordic nRF52840 single-chip controller with integrated BlueRadios nBlue™ Bluetooth AT.s LE Command Set.

For information on the BlueRadios nBlue Bluetooth AT.s LE Command Set please contact your local Panasonic Sales Representative. Bluetooth 5 features additionally a higher symbol rate of 2 Mbps using the high-speed LE 2M PHY or a significantly longer range using the LE Coded PHY at 125 kb/s. The new channel selection algorithm (CSA#2) improves the performance in high interference environments. Furthermore, the new LE advertising extensions allow for much larger amounts of data to be broadcasted in connectionless scenarios.

An output power of up to 8 dBm and the high sensitivity of the nRF52840 in combination with the LE Coded PHY make the NEW PAN1780AT Series RF Module from Panasonic very attractive in applications where a long range is required. In addition, the ultra-low current consumption of the NEW PAN1780AT Series makes it an ideal choice for battery powered devices and also supports Type 2 Near Field Communication (NFC-A) for use in simplified pairing and payment solutions (external antenna required).

The NEW PAN1780AT Evaluation Kit is provided to support rapid prototyping with the PAN1780AT Series RF Module.
