Aluminum Electrolytic Capacitors (Radial Lead Type)

High reliability, long life, low impedance and high ripple current.

Series table for lineup Aluminum Electrolytic Capacitors (Radial Lead Type)
Series/Type	Datasheet	Operating Temperature Range (°C)	Endurance (h)	Reach (Report of Confirmation)	Features	Capacitance Range (µF)	RoHS (Compliance Certificate)	Rated Voltage Range (DC) (V)	AEC-Q200
FS-A		-40 to +105	5000 to 10000	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)	･Low Impedance ･Miniaturization	27 to 10000	RoHS compliant (Please refer to the Related Information.)	6.3 to 100
FP-A		-55 to +105	4000 to 5000	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)	･High ripple current ･Large capacitance	510 to 2000	RoHS compliant (Please refer to the Related Information.)	25 to 35	AEC-Q200 compliant
FR-A		-40 to +105	5000 to 10000	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)	･Low Impedance	4.7 to 8200	RoHS compliant (Please refer to the Related Information.)	6.3 to 100
FM-A		-40 to +105	4000 to 7000	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)	･Low Impedance	22 to 6800	RoHS compliant (Please refer to the Related Information.)	6.3 to 50
FK-A		-55 to +105	4000 to 5000	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)	･Low impedance (10 to 30% less than FC series)	180 to 12000	RoHS compliant (Please refer to the Related Information.)	6.3 to 35	AEC-Q200 compliant
FC-A		-55 to +105	3000 to 5000	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)	･Low impedance	2.2 to 15000	RoHS compliant (Please refer to the Related Information.)	6.3 to 100	AEC-Q200 compliant
EE-A		-25 to +105	8000 to 10000	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)	･High ripple current	10 to 330	RoHS compliant (Please refer to the Related Information.)	160 to 450
ED-A		-25 to +105	8000 to 10000	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)	･High ripple current (at high frequency)	10 to 330	RoHS compliant (Please refer to the Related Information.)	160 to 450
EB-A		-40(-25) to +105	5000 to 10000	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)	･Long life ･Low profile	2.2 to 3300	RoHS compliant (Please refer to the Related Information.)	10 to 450
TP-A		①-40 to +135 ②-40 to +125	①3000 to 5000 ②2000	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)	･High ripple (20% to 40% higher than TA series)	100 to 5100	RoHS compliant (Please refer to the Related Information.)	25 to 35	AEC-Q200 compliant

Series table for lineup Aluminum Electrolytic Capacitors (Radial Lead Type)
Series/Type	Datasheet	Operating Temperature Range (°C)	Endurance (h)	Reach (Report of Confirmation)	Features	Capacitance Range (µF)	RoHS (Compliance Certificate)	Rated Voltage Range (DC) (V)	AEC-Q200
FS-A		-40 to +105	5000 to 10000	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)	･Low Impedance ･Miniaturization	27 to 10000	RoHS compliant (Please refer to the Related Information.)	6.3 to 100
FP-A		-55 to +105	4000 to 5000	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)	･High ripple current ･Large capacitance	510 to 2000	RoHS compliant (Please refer to the Related Information.)	25 to 35	AEC-Q200 compliant
FR-A		-40 to +105	5000 to 10000	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)	･Low Impedance	4.7 to 8200	RoHS compliant (Please refer to the Related Information.)	6.3 to 100
FM-A		-40 to +105	4000 to 7000	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)	･Low Impedance	22 to 6800	RoHS compliant (Please refer to the Related Information.)	6.3 to 50
FK-A		-55 to +105	4000 to 5000	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)	･Low impedance (10 to 30% less than FC series)	180 to 12000	RoHS compliant (Please refer to the Related Information.)	6.3 to 35	AEC-Q200 compliant
FC-A		-55 to +105	3000 to 5000	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)	･Low impedance	2.2 to 15000	RoHS compliant (Please refer to the Related Information.)	6.3 to 100	AEC-Q200 compliant
EE-A		-25 to +105	8000 to 10000	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)	･High ripple current	10 to 330	RoHS compliant (Please refer to the Related Information.)	160 to 450
ED-A		-25 to +105	8000 to 10000	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)	･High ripple current (at high frequency)	10 to 330	RoHS compliant (Please refer to the Related Information.)	160 to 450
EB-A		-40(-25) to +105	5000 to 10000	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)	･Long life ･Low profile	2.2 to 3300	RoHS compliant (Please refer to the Related Information.)	10 to 450
TP-A		①-40 to +135 ②-40 to +125	①3000 to 5000 ②2000	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)	･High ripple (20% to 40% higher than TA series)	100 to 5100	RoHS compliant (Please refer to the Related Information.)	25 to 35	AEC-Q200 compliant
