EEH-ZT Series (SMD High Temp. Reflow)

The EEH-ZT Series Conductive Polymer Hybrid Aluminum Capacitors feature an operating temperature range of -55℃ to +125℃ and a rated voltage range of 25 V to 63 V. The EEH-ZT Series can withstand high temperatures of 125℃ for 4000 hours and are available in Vibration-Proof variants upon request. These parts are ideal where high temperature and high current capability are demanded by the application.

Features

High Temperature Lead-Free Reflow
Endurance: 4000-Hour Life At 125℃ (High Temperature)
Low ESR And High Ripple Current
Broad Operating Temperature: -55℃ to +125℃
High Withstand Voltage (25V to 63V)
Vibration-Proof Product Is Available Upon Request
AEC-Q200 and RoHS / REACH Compliant

Benefits

Long Life At High Operating Temperature
High Performance
Safe Operation
Automotive Quality

An AEC-Q200 Compliant Series

Panasonic components specified as AEC-Q200 Compliant are consistently designed into automotive systems. However, today’s Design Engineers are specifying AEC-Q200 components to meet the high-quality standards of devices beyond automotive applications.

Parts that pass the AEC tests are qualified, high-quality components that can be used in critical environments. Therefore, there should be no need to conduct other component level tests saving both time and expense.

Current AEC-Q200 Standard documents developed by the AEC Component Technical Committee are available on the AEC website. The AEC is an organization based in the U.S. that sets qualification standards for the supply of components in the automotive electronics industry.

If your next device requires components that meet the Automotive Electronics Council (AEC) requirements for components suitable for harsh automotive environments, think Panasonic!

Download a complete list of Panasonic AEC-Q200 Compliant Component Series and specify reliably!

EEH-ZT(U) Series (SMD, High Temp. Reflow)

WHICH PART IS SUITABLE FOR YOU?

For larger capacitance needs, Panasonic also manufactures EEH-ZT(U) Series Conductive Polymer Hybrid Aluminum Capacitors. The EEH-ZT(U) Series features one of the highest endurance ratings in the industry: 4000 Hours at 125°C and 135°C. Their capacitance is also significantly larger, 170% higher than that of the ZT Series.

Learn more about the EEH-ZT(U) Series to find which parts are suitable for your needs!

Models table for series EEH-ZT Series (SMD High Temp. Reflow)
Part No.	Body Type	Polarity Type	Rated Voltage (V)	Capacitance (µF)	Capacitance Tolerance (%)	Tangent Of Loss Angle (Max.)	Leakage Current (Max.) (μA)	Operating Temperature Range (°C)	Body Diameter (mm)	Body Length (mm)	Rated Ripple Current (Freq.) (Hz)	Rated Ripple Current (mA)	Rated Ripple Current (Unit)	E.S.R.-1 (Frequency) (Hz)	E.S.R.-1 (Max. Value) (mΩ)	Endurance (h)	Forming & Packaging Feature	Appearance	Minimum Packaging Quantity (piece)	Weight (Typ.) (g)
EEH-ZT1H101V	Surface mount type (vertical mount style)	Polar	50	100	-20 to 20	0.1	50	-55 to 125	10	10.5	100000	2900	ｍArms	100000	23	4000	Embossed carrier taping (reel packing)	Sheathless (metal case)	500	1.639
EEH-ZT1H101P	Surface mount type (vertical mount style)	Polar	50	100	-20 to 20	0.1	50	-55 to 125	10	10.2	100000	2900	ｍArms	100000	23	4000	Embossed carrier taping (reel packing)	Sheathless (metal case)	500	1.408
EEH-ZT1J470P	Surface mount type (vertical mount style)	Polar	63	47	-20 to 20	0.08	29.6	-55 to 125	8	10.2	100000	2400	ｍArms	100000	32	4000	Embossed carrier taping (reel packing)	Sheathless (metal case)	500	0.908
EEH-ZT1J680P	Surface mount type (vertical mount style)	Polar	63	68	-20 to 20	0.08	42.8	-55 to 125	10	10.2	100000	2800	ｍArms	100000	25	4000	Embossed carrier taping (reel packing)	Sheathless (metal case)	500	1.408
EEH-ZT1H121P	Surface mount type (vertical mount style)	Polar	50	120	-20 to 20	0.1	60	-55 to 125	10	10.2	100000	2900	ｍArms	100000	23	4000	Embossed carrier taping (reel packing)	Sheathless (metal case)	500	1.408
EEH-ZT1J820P	Surface mount type (vertical mount style)	Polar	63	82	-20 to 20	0.08	51.6	-55 to 125	10	10.2	100000	2800	ｍArms	100000	25	4000	Embossed carrier taping (reel packing)	Sheathless (metal case)	500	1.408
EEH-ZT1J470V	Surface mount type (vertical mount style)	Polar	63	47	-20 to 20	0.08	29.6	-55 to 125	8	10.5	100000	2400	ｍArms	100000	32	4000	Embossed carrier taping (reel packing)	Sheathless (metal case)	500	0.994
EEH-ZT1J330V	Surface mount type (vertical mount style)	Polar	63	33	-20 to 20	0.08	20.7	-55 to 125	8	10.5	100000	2400	ｍArms	100000	32	4000	Embossed carrier taping (reel packing)	Sheathless (metal case)	500	0.994
EEH-ZT1H680P	Surface mount type (vertical mount style)	Polar	50	68	-20 to 20	0.1	34	-55 to 125	8	10.2	100000	2700	ｍArms	100000	25	4000	Embossed carrier taping (reel packing)	Sheathless (metal case)	500	0.908
EEH-ZT1J680V	Surface mount type (vertical mount style)	Polar	63	68	-20 to 20	0.08	42.8	-55 to 125	10	10.5	100000	2800	ｍArms	100000	25	4000	Embossed carrier taping (reel packing)	Sheathless (metal case)	500	1.639

Models table for series EEH-ZT Series (SMD High Temp. Reflow)
Part No.	Body Type	Polarity Type	Rated Voltage (V)	Capacitance (µF)	Capacitance Tolerance (%)	Tangent Of Loss Angle (Max.)	Leakage Current (Max.) (μA)	Operating Temperature Range (°C)	Body Diameter (mm)	Body Length (mm)	Rated Ripple Current (Freq.) (Hz)	Rated Ripple Current (mA)	Rated Ripple Current (Unit)	E.S.R.-1 (Frequency) (Hz)	E.S.R.-1 (Max. Value) (mΩ)	Endurance (h)	Forming & Packaging Feature	Appearance	Minimum Packaging Quantity (piece)	Weight (Typ.) (g)
EEH-ZT1H101V	Surface mount type (vertical mount style)	Polar	50	100	-20 to 20	0.1	50	-55 to 125	10	10.5	100000	2900	ｍArms	100000	23	4000	Embossed carrier taping (reel packing)	Sheathless (metal case)	500	1.639
EEH-ZT1H101P	Surface mount type (vertical mount style)	Polar	50	100	-20 to 20	0.1	50	-55 to 125	10	10.2	100000	2900	ｍArms	100000	23	4000	Embossed carrier taping (reel packing)	Sheathless (metal case)	500	1.408
EEH-ZT1J470P	Surface mount type (vertical mount style)	Polar	63	47	-20 to 20	0.08	29.6	-55 to 125	8	10.2	100000	2400	ｍArms	100000	32	4000	Embossed carrier taping (reel packing)	Sheathless (metal case)	500	0.908
EEH-ZT1J680P	Surface mount type (vertical mount style)	Polar	63	68	-20 to 20	0.08	42.8	-55 to 125	10	10.2	100000	2800	ｍArms	100000	25	4000	Embossed carrier taping (reel packing)	Sheathless (metal case)	500	1.408
EEH-ZT1H121P	Surface mount type (vertical mount style)	Polar	50	120	-20 to 20	0.1	60	-55 to 125	10	10.2	100000	2900	ｍArms	100000	23	4000	Embossed carrier taping (reel packing)	Sheathless (metal case)	500	1.408
EEH-ZT1J820P	Surface mount type (vertical mount style)	Polar	63	82	-20 to 20	0.08	51.6	-55 to 125	10	10.2	100000	2800	ｍArms	100000	25	4000	Embossed carrier taping (reel packing)	Sheathless (metal case)	500	1.408
EEH-ZT1J470V	Surface mount type (vertical mount style)	Polar	63	47	-20 to 20	0.08	29.6	-55 to 125	8	10.5	100000	2400	ｍArms	100000	32	4000	Embossed carrier taping (reel packing)	Sheathless (metal case)	500	0.994
EEH-ZT1J330V	Surface mount type (vertical mount style)	Polar	63	33	-20 to 20	0.08	20.7	-55 to 125	8	10.5	100000	2400	ｍArms	100000	32	4000	Embossed carrier taping (reel packing)	Sheathless (metal case)	500	0.994
EEH-ZT1H680P	Surface mount type (vertical mount style)	Polar	50	68	-20 to 20	0.1	34	-55 to 125	8	10.2	100000	2700	ｍArms	100000	25	4000	Embossed carrier taping (reel packing)	Sheathless (metal case)	500	0.908
EEH-ZT1J680V	Surface mount type (vertical mount style)	Polar	63	68	-20 to 20	0.08	42.8	-55 to 125	10	10.5	100000	2800	ｍArms	100000	25	4000	Embossed carrier taping (reel packing)	Sheathless (metal case)	500	1.639
