EEH-ZT Series (THT Tape And Box)

Panasonic’s EEH-ZT Series Polymer Hybrid Capacitors are now available in Leaded THT Tape and Box Ammo Pack options.

AEC-Q200 qualification for automotive and harsh environment applications ensures optimal quality and reliability. These parts are ideal where high temperature and high current capability are demanded by the application.

Features and Benefits

  • Leaded
  • Ammo Pack Taping For THT Type: Only Ø8 and Ø10 Products
  • High Ripple and Low ESR
  • AEC-Q200 Compliant
  • RoHS and REACH Compliant
Series image for EEH-ZT Series (THT Tape And Box)

EEH-ZT Series (THT Tape And Box)

Part number list

Results 12
Models table for series EEH-ZT Series (THT Tape And Box)
Part No.DatasheetBody TypePolarity Type Rated Voltage (V)Capacitance (µF)Capacitance Tolerance (%)Tangent Of Loss Angle (Max.)Leakage Current (Max.) (μA)Operating Temperature Range (°C)Body Diameter (mm)Body Length (mm)Lead (Terminal) Pitch (mm)Rated Ripple Current (Freq.) (Hz)Rated Ripple Current (mA)Rated Ripple Current (Unit)E.S.R.-1 (Frequency) (Hz)E.S.R.-1 (Max. Value) (mΩ)Endurance (h)Forming & Packaging FeatureAppearanceMinimum Packaging Quantity (piece)Weight (Typ.) (g)
EEH-AZT1E331B
Radial lead type
Polar
25
330
-20 to 20
0.14
82.5
-55 to 125
10
9.5
5
100000
3500
ｍArms
100000
16
4000
Lead taping (ammo packing), standard
Sheathless (metal case)
500
1.251
EEH-AZT1H101B
Radial lead type
Polar
50
100
-20 to 20
0.1
50
-55 to 125
10
9.5
5
100000
2900
ｍArms
100000
23
4000
Lead taping (ammo packing), standard
Sheathless (metal case)
500
1.251
EEH-AZT1H680B
Radial lead type
Polar
50
68
-20 to 20
0.1
34
-55 to 125
8
9.5
3.5
100000
2700
ｍArms
100000
25
4000
Lead taping (ammo packing), standard
Sheathless (metal case)
1000
0.976
EEH-AZT1H121B
Radial lead type
Polar
50
120
-20 to 20
0.1
60
-55 to 125
10
9.5
5
100000
2900
ｍArms
100000
23
4000
Lead taping (ammo packing), standard
Sheathless (metal case)
500
1.251
EEH-AZT1V271B
Radial lead type
Polar
35
270
-20 to 20
0.12
94.5
-55 to 125
10
9.5
5
100000
3500
ｍArms
100000
16
4000
Lead taping (ammo packing), standard
Sheathless (metal case)
500
1.251
EEH-AZT1J470B
Radial lead type
Polar
63
47
-20 to 20
0.08
29.6
-55 to 125
8
9.5
3.5
100000
2400
ｍArms
100000
32
4000
Lead taping (ammo packing), standard
Sheathless (metal case)
1000
0.976
EEH-AZT1J560B
Radial lead type
Polar
63
56
-20 to 20
0.08
35.2
-55 to 125
10
9.5
5
100000
2800
ｍArms
100000
25
4000
Lead taping (ammo packing), standard
Sheathless (metal case)
500
1.251
EEH-AZT1V151B
Radial lead type
Polar
35
150
-20 to 20
0.12
52.5
-55 to 125
8
9.5
3.5
100000
2900
ｍArms
100000
22
4000
Lead taping (ammo packing), standard
Sheathless (metal case)
1000
0.976
EEH-AZT1J680B
Radial lead type
Polar
63
68
-20 to 20
0.08
42.8
-55 to 125
10
9.5
5
100000
2800
ｍArms
100000
25
4000
Lead taping (ammo packing), standard
Sheathless (metal case)
500
1.251
EEH-AZT1J330B
Radial lead type
Polar
63
33
-20 to 20
0.08
20.7
-55 to 125
8
9.5
3.5
100000
2400
ｍArms
100000
32
4000
Lead taping (ammo packing), standard
Sheathless (metal case)
1000
0.976
AEC-Q200 Selection Guide
An AEC-Q200 Compliant Series

Panasonic components specified as AEC-Q200 Compliant are consistently designed into automotive systems.  However, today’s Design Engineers are specifying AEC-Q200 components to meet the high-quality standards of devices beyond automotive applications.

Parts that pass the AEC tests are qualified, high-quality components that can be used in critical environments.  Therefore, there should be no need to conduct other component level tests saving both time and expense.

Current AEC-Q200 Standard documents developed by the AEC Component Technical Committee are available on the AEC website. The AEC is an organization based in the U.S. that sets qualification standards for the supply of components in the automotive electronics industry.

If your next device requires components that meet the Automotive Electronics Council (AEC) requirements for components suitable for harsh automotive environments, think Panasonic!

Download a complete list of Panasonic AEC-Q200 Compliant Component Series and specify reliably!
