Part Number List

Results 45
Models table for series Turquoise Stroke Switches (ASQ1)
Part No.DatasheetContact ArrangementActuatorMounting WayTerminal TypeOperating ForceContact MaterialTerminal and Direction of Lead WireLever PositionSpecificationsElectrical LifeProtective Construction
SPDT
Simulated leaf lever
Mounting hole 3 mm without boss type
PC board terminal
1.5N
Au plating on both sides of sliding contact
Bottom type
Standard
1mA 5V DC to 100mA 30V DC
Min. 5 x 105 5V DC 1mA (Resistive load)
IP67 (Wire leads type except metal terminal part)
SPDT
Simulated leaf lever
Right side pin type
Solder terminal
1.5N
Au plating on both sides of sliding contact
-
Standard
1mA 5V DC to 100mA 30V DC
Min. 5 x 105 5V DC 1mA (Resistive load)
IP67 (Wire leads type except metal terminal part)
SPST-NC
Pin plunger
Mounting hole 3 mm standard type
Wire leads left side type
1.5N
Au plating on both sides of sliding contact
Left side type
Standard
1mA 5V DC to 100mA 30V DC
Min. 5 x 105 5V DC 1mA (Resistive load)
IP67 (Wire leads type except metal terminal part)
SPDT
Simulated leaf lever
Right 2 boss type
Solder terminal
1.5N
Au plating on both sides of sliding contact
-
Standard
1mA 5V DC to 100mA 30V DC
Min. 5 x 105 5V DC 1mA (Resistive load)
IP67 (Wire leads type except metal terminal part)
SPST-NC
Leaf lever
Mounting hole 3 mm standard type
Wire leads right side type
1.7N
Au plating on both sides of sliding contact
Right side type
Standard
1mA 5V DC to 100mA 30V DC
Min. 5 x 105 5V DC 1mA (Resistive load)
IP67 (Wire leads type except metal terminal part)
SPDT
Pin plunger
Mounting hole 3 mm standard type
Wire leads bottom type
1.5N
Au plating on both sides of sliding contact
Bottom type
Standard
1mA 5V DC to 100mA 30V DC
Min. 5 x 105 5V DC 1mA (Resistive load)
IP67 (Wire leads type except metal terminal part)
SPST-NO
Leaf lever
Mounting hole 3 mm standard type
Wire leads bottom type
1.7N
Au plating on both sides of sliding contact
Bottom type
Standard
1mA 5V DC to 100mA 30V DC
Min. 5 x 105 5V DC 1mA (Resistive load)
IP67 (Wire leads type except metal terminal part)
SPDT
Leaf lever
Mounting hole 3 mm standard type
PC board right angle terminal
1.7N
Au plating on both sides of sliding contact
-
Standard
1mA 5V DC to 100mA 30V DC
Min. 5 x 105 5V DC 1mA (Resistive load)
IP67 (Wire leads type except metal terminal part)
SPDT
Pin plunger
Mounting hole 3 mm standard type
PC board left angle terminal
1.5N
Au plating on both sides of sliding contact
-
Standard
1mA 5V DC to 100mA 30V DC
Min. 5 x 105 5V DC 1mA (Resistive load)
IP67 (Wire leads type except metal terminal part)
SPST-NC
Leaf lever
Mounting hole 3 mm standard type
Wire leads bottom type
1.7N
Au plating on both sides of sliding contact
Bottom type
Standard
1mA 5V DC to 100mA 30V DC
Min. 5 x 105 5V DC 1mA (Resistive load)
IP67 (Wire leads type except metal terminal part)
