Specifications
| Item | Performance characteristics |
|---|---|
| Figure of Output | 13GHz |
| Contact Arrangement | SP6T (with termination type) |
| Operating Function | Fail-safe (with indicator) |
| Coil Voltage | 4.5V DC |
| Operation Terminal | Solder terminal |
| Terminating Resistor | With termination |
| Datasheet Attached | Yes |
| V.S.W.R | Max. 1.50 |
| Impedance | 50 ohm |
| Insertion (Without D.U.T Board's Loss) | Max. 0.4 dB |
| Isolation | Min. 65 dB |
| Contact Material | Au plating |
| Contact Rating | 120W (at 3GHz) |
| Rated operating power | 840mW |
| Breakdown Voltage (Contact-Contact) (Initial) | 500Vrms |
| Breakdown Voltage (Initial) : Between Contact And Coil | 500Vrms |
| Expected Life: Mechanical | 5x10^6 |
| Expected Life: Electrical | 5x10^6 |
| Ambient Temperature | -55deg to +85deg |
