Detector Switches are used to “detect” internal mechanical movements and convert human manual operations, such as the opening of a door , to electronic signals.

Panasonic Detector Switches use a mechanical sliding spring design to ensure consistent signal output. They also feature long travel, thin profile, compact size, light weight, highly flexible actuation angles and surface mount or J-bent terminal mounting options.

In some applications, Detector Switches are used to replace Encoders as a lower cost solution.

Detector Switches

Series comparison (9)

ESE-11 Series (Plunger Type Actuator)

View series

Specifications

ESE-13 Series Detector Switch (4.2mm x 3.6mm x 1.2mm, Horizontal SMD, Vertical Operation)

View series

Specifications

ESE-16 Series Detector Switch (2.2mm x 3.5mm x 1.5mm, Horizontal SMD, Top Operation)

View series

Specifications

ESE-18 Series Detector Switch (4.0mm x 4.4mm x 1.2mm, Horizontal SMD, Side Operation)

View series

Specifications

ESE-22 Series (Horizontal and Vertical Actuation Angles)

View series

Specifications

ESE-24 Series Detector Switch (7.5 x 5.6 x 3.0 mm, Various Orientations, Bidirectional Operation)

View series

Specifications

ESE-31 Series Detector Switch (5.9mm x 5.4mm x 1.7mm, Horizontal SMD, Side Operation)

View series

Specifications

ESE-58 Series Detector Switch (3.5mm x 3.0mm x 0.9mm, Horizontal SMD, Side Operation)

View series

Specifications

ESE-23 Series Detector Switch (4.1mm × 5.0mm x 1.5mm, Horizontal SMD, Side Operation)

View series

Specifications
