Specifications
| Item | Performance characteristics |
|---|---|
| External Dimensions (LxWxH) (mm) | 4.9 x 4.0 x 0.70 |
| Mounting Height (mm) (mm) | 0.70 |
| Operating Force (N) | 1.65 |
| Travel Type | Short Push Travel |
| Operating Life | 1,000,000 cycles |
| Ground Terminal | Without |
| Type | Snap action / Push-on type SPST |
| External Dimensions (LxW) (mm) | 4.9 x 4.0 |
| External Dimensions (H) (mm) | 0.70 |
| Operating Direction | Top push |
| Applicable Soldering | Reflow |
| Mounting Type | SMD |
| Rating | 10μA 2V DC to 20mA 15V DC (Resistive load) |
| Contact Resistance (M&Omega: Max.) | 500 |
| Insulation Resistance (MΩ Min. at 100V DC) | 50 |
| Dielectric Withstanding Voltage | 250 V AC (for 1minute) |
| Bouncing | 10ms max. (ON, OFF) |
| Travel (mm) | 0.20 |
| Protective Construction | IP67 |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -40°C to +85°C (Bulk) -20°C to +60°C (Taping) |
| Terminal Type | Straight |
| Push Plate <br> (Actuator) | With |
| Boss | Without |
| Packaging | Embossed Taping (Reel Pack) |
| Minimum Quantity/Packing Unit | 10,000 pcs. |
| Quantity/Carton | 50,000 pcs. |
Stock check
EVPBK2A6B000
