Specifications
| Item | Performance characteristics |
|---|---|
| External Dimensions (LxWxH) (mm) | 4.1 x 4.1 x 0.43 |
| Mounting Height (mm) (mm) | 0.43 |
| Operating Force (N) | 2.4 |
| Push Plate <br> (Actuator) | Without |
| Type | Snap action / Push-on type SPST |
| External Dimensions (LxW) (mm) | 4.1 x 4.1 |
| External Dimensions (H) (mm) | 0.43 |
| Dimensions Excluding Push Plate (mm) | 0.43 |
| Operating Direction | Top push |
| Applicable Soldering | Reflow |
| Mounting Type | SMD |
| Rating | 10μA 2V DC to 20mA 15V DC (Resistive load) |
| Contact Resistance (M&Omega: Max.) | 500 |
| Insulation Resistance (MΩ Min. at 100V DC) | 50 |
| Dielectric Withstanding Voltage | 100 V AC (for 1minute) |
| Bouncing | 3ms max. (ON) 10ms max. (OFF) |
| Travel Type | Short Push Travel |
| Travel (mm) | 0.20 |
| Operating Life | 500,000 cycles |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C (Bulk) -20°C to +60°C (Taping) |
| Terminal Type | J-bent |
| Ground Terminal | With |
| Boss | Without |
| Packaging | Embossed Taping (Reel Pack) |
| Minimum Quantity/Packing Unit | 10,000 pcs. |
| Quantity/Carton | 50,000 pcs. |
Stock check
EVQ9P6B40
