ASQ1 Series (Sealed And Silent Ultra-Long Stroke Switches)

ASQ1 Series is a 1 Form C (SPDT) Long Stroke and Sliding Contact Construction Sealed Switch with a height of 10.1mm. This Seal Type Snap Action Switch also supports high operating life of up to 500,000 cycles. It has a low current/voltage rating of 1 mA/5 V DC to 100 mA/30 VDC which makes the ASQ1 Series (Sealed And Silent Ultra-Long Stroke Switch) suitable for applications such as automotive (detection of door opening and closing and shift lever position), home appliances (vacuum cleaners, air conditioners, washing machines), security locks, sliding doors, power windows and power tools.

Features and Benefits of ASQ1 Series

Miniature Size With External Dimensions: 13.3 X 5.4 X 10.1mm
For Pin Plunger Type, It Maintains A Long Stroke OT (Over Travel) With Over 2.2 Mm On The NO Side And Over 2.5 Mm On The NC Side.
Since Contact Force Does Not Depend On The Operation Stroke, The Range Of Possible Use Over The Entire Stroke Is Greatly Increased.
High Contact Reliability To Support Low Level Switching Loads
Highly Effective Sealing For Resistance Against Adverse Environments
Silent Operation With Sliding Contact
Protection Grade: IP67

ASQ1 Series (Sealed And Silent Ultra-Long Stroke Switches)

Part number list

Results 45

Models table for series ASQ1 Series (Sealed And Silent Ultra-Long Stroke Switches)
Part No.	Datasheet	Contact Arrangement	Mounting Way	Actuator	Terminal Type	Operating Force	Contact Material	Terminal and Direction of Lead Wire	Lever Position	Specifications	Electrical Life	Protective Construction
ASQ10330		SPST-NO	Mounting hole 3 mm standard type	Pin plunger	Wire leads left side type	1.5N	Au plating on both sides of sliding contact	Left side type	Standard	1mA 5V DC to 100mA 30V DC	Min. 5 x 10⁵ 5V DC 1mA (Resistive load)	IP67 (Wire leads type except metal terminal part)
ASQ10338		SPST-NO	Mounting hole 3 mm standard type	Simulated leaf lever	Wire leads left side type	1.5N	Au plating on both sides of sliding contact	Left side type	Standard	1mA 5V DC to 100mA 30V DC	Min. 5 x 10⁵ 5V DC 1mA (Resistive load)	IP67 (Wire leads type except metal terminal part)
ASQ10617		SPDT	Mounting hole 3 mm standard type	Leaf lever	Wire leads bottom type	1.7N	Au plating on both sides of sliding contact	Bottom type	Standard	1mA 5V DC to 100mA 30V DC	Min. 5 x 10⁵ 5V DC 1mA (Resistive load)	IP67 (Wire leads type except metal terminal part)
ASQ10610		SPDT	Mounting hole 3 mm standard type	Pin plunger	Wire leads bottom type	1.5N	Au plating on both sides of sliding contact	Bottom type	Standard	1mA 5V DC to 100mA 30V DC	Min. 5 x 10⁵ 5V DC 1mA (Resistive load)	IP67 (Wire leads type except metal terminal part)
ASQ11518		SPDT	Mounting hole 3 mm without boss type	Simulated leaf lever	PC board terminal	1.5N	Au plating on both sides of sliding contact	Bottom type	Standard	1mA 5V DC to 100mA 30V DC	Min. 5 x 10⁵ 5V DC 1mA (Resistive load)	IP67 (Wire leads type except metal terminal part)
ASQ14410		SPDT	Right side pin type	Pin plunger	Solder terminal	1.5N	Au plating on both sides of sliding contact	-	Standard	1mA 5V DC to 100mA 30V DC	Min. 5 x 10⁵ 5V DC 1mA (Resistive load)	IP67 (Wire leads type except metal terminal part)
ASQ10627		SPST-NC	Mounting hole 3 mm standard type	Leaf lever	Wire leads bottom type	1.7N	Au plating on both sides of sliding contact	Bottom type	Standard	1mA 5V DC to 100mA 30V DC	Min. 5 x 10⁵ 5V DC 1mA (Resistive load)	IP67 (Wire leads type except metal terminal part)
ASQ10618		SPDT	Mounting hole 3 mm standard type	Simulated leaf lever	Wire leads bottom type	1.5N	Au plating on both sides of sliding contact	Bottom type	Standard	1mA 5V DC to 100mA 30V DC	Min. 5 x 10⁵ 5V DC 1mA (Resistive load)	IP67 (Wire leads type except metal terminal part)
ASQ10630		SPST-NO	Mounting hole 3 mm standard type	Pin plunger	Wire leads bottom type	1.5N	Au plating on both sides of sliding contact	Bottom type	Standard	1mA 5V DC to 100mA 30V DC	Min. 5 x 10⁵ 5V DC 1mA (Resistive load)	IP67 (Wire leads type except metal terminal part)
ASQ10717		SPDT	Mounting hole 3 mm standard type	Leaf lever	PC board right angle terminal	1.7N	Au plating on both sides of sliding contact	-	Standard	1mA 5V DC to 100mA 30V DC	Min. 5 x 10⁵ 5V DC 1mA (Resistive load)	IP67 (Wire leads type except metal terminal part)

Models table for series ASQ1 Series (Sealed And Silent Ultra-Long Stroke Switches)
Part No.	Datasheet	Contact Arrangement	Mounting Way	Actuator	Terminal Type	Operating Force	Contact Material	Terminal and Direction of Lead Wire	Lever Position	Specifications	Electrical Life	Protective Construction
ASQ10330		SPST-NO	Mounting hole 3 mm standard type	Pin plunger	Wire leads left side type	1.5N	Au plating on both sides of sliding contact	Left side type	Standard	1mA 5V DC to 100mA 30V DC	Min. 5 x 10⁵ 5V DC 1mA (Resistive load)	IP67 (Wire leads type except metal terminal part)
ASQ10338		SPST-NO	Mounting hole 3 mm standard type	Simulated leaf lever	Wire leads left side type	1.5N	Au plating on both sides of sliding contact	Left side type	Standard	1mA 5V DC to 100mA 30V DC	Min. 5 x 10⁵ 5V DC 1mA (Resistive load)	IP67 (Wire leads type except metal terminal part)
ASQ10617		SPDT	Mounting hole 3 mm standard type	Leaf lever	Wire leads bottom type	1.7N	Au plating on both sides of sliding contact	Bottom type	Standard	1mA 5V DC to 100mA 30V DC	Min. 5 x 10⁵ 5V DC 1mA (Resistive load)	IP67 (Wire leads type except metal terminal part)
ASQ10610		SPDT	Mounting hole 3 mm standard type	Pin plunger	Wire leads bottom type	1.5N	Au plating on both sides of sliding contact	Bottom type	Standard	1mA 5V DC to 100mA 30V DC	Min. 5 x 10⁵ 5V DC 1mA (Resistive load)	IP67 (Wire leads type except metal terminal part)
ASQ11518		SPDT	Mounting hole 3 mm without boss type	Simulated leaf lever	PC board terminal	1.5N	Au plating on both sides of sliding contact	Bottom type	Standard	1mA 5V DC to 100mA 30V DC	Min. 5 x 10⁵ 5V DC 1mA (Resistive load)	IP67 (Wire leads type except metal terminal part)
ASQ14410		SPDT	Right side pin type	Pin plunger	Solder terminal	1.5N	Au plating on both sides of sliding contact	-	Standard	1mA 5V DC to 100mA 30V DC	Min. 5 x 10⁵ 5V DC 1mA (Resistive load)	IP67 (Wire leads type except metal terminal part)
ASQ10627		SPST-NC	Mounting hole 3 mm standard type	Leaf lever	Wire leads bottom type	1.7N	Au plating on both sides of sliding contact	Bottom type	Standard	1mA 5V DC to 100mA 30V DC	Min. 5 x 10⁵ 5V DC 1mA (Resistive load)	IP67 (Wire leads type except metal terminal part)
ASQ10618		SPDT	Mounting hole 3 mm standard type	Simulated leaf lever	Wire leads bottom type	1.5N	Au plating on both sides of sliding contact	Bottom type	Standard	1mA 5V DC to 100mA 30V DC	Min. 5 x 10⁵ 5V DC 1mA (Resistive load)	IP67 (Wire leads type except metal terminal part)
ASQ10630		SPST-NO	Mounting hole 3 mm standard type	Pin plunger	Wire leads bottom type	1.5N	Au plating on both sides of sliding contact	Bottom type	Standard	1mA 5V DC to 100mA 30V DC	Min. 5 x 10⁵ 5V DC 1mA (Resistive load)	IP67 (Wire leads type except metal terminal part)
ASQ10717		SPDT	Mounting hole 3 mm standard type	Leaf lever	PC board right angle terminal	1.7N	Au plating on both sides of sliding contact	-	Standard	1mA 5V DC to 100mA 30V DC	Min. 5 x 10⁵ 5V DC 1mA (Resistive load)	IP67 (Wire leads type except metal terminal part)
