PAN9320 Embedded Wi-Fi Module

PAN9320 module



Embedded WiFi Modules for Easy Deployment

Panasonic's PAN9310/9320 Series is a standalone 2.4GHz WiFi module, supporting the IEEE 802.11 b/g/n standards designed for applications where a small form factor and high throughput data rates are required.



The module is a cost-effective, power efficient solution for WLAN applications. The PAN9310/9320 Series combines a high performance CPU, high sensitivity (-98dBm) wireless radio, baseband processor, medium access controller, encryption unit, boot ROM with patching capability, internal SRAM and in-system programmable flash memory. The module’s integrated memory is available to the application to store web content such as html pages or image data.

Coincident support of access point and infrastructure modes enable easy setup up allowing WiFi connections from the PAN9310/9320 Series to smart devices and home network routers, simultaniously. WLAN SoC firmware enables client (STA), micro access point (uAP) and Ad-hoc mode (Wi-Fi direct) applications. Transparent mode permits data to be sent from the PAN9310/9320 Series UART unmodified to the air interface to smart devices, web servers or pc applications.

The PAN9310/9320 Series is qualified to the IEEE 802.11 b/g/n standards. All Panasonic Bluetooth RF modules carry FCC, IC, CE and Bluetooth certifications. Panasonic calibrates and tests every module eliminating a time consuming application production process and cost. Panasonic cost engineering lowers component count and the application BOM. With a fully shielded case, integrated crystal oscillators and chip antenna contained in a footprint of just 29 x 13.5 x 2.66 mm³.

Model List

Found 1 matches. Display 1 - 1 matches.
Part No.sort descendingData SheetSize (mm)Used IcsRx Sensitivity (dBm)Tx Power (max.)Operating Temp.Current Consum.Frequency RangeData Rate (max. air)Parts Inventory
   Column active Filter
Close

Filter by Size (mm)

Column active Filter
Close

Filter by Used Ics

Column active Filter
Close

Filter by Rx Sensitivity (dBm)

Column active Filter
Close

Filter by Tx Power (max.)

Column active Filter
Close

Filter by Operating Temp.

Column active Filter
Close

Filter by Current Consum.

Column active Filter
Close

Filter by Frequency Range

Column active Filter
Close

Filter by Data Rate (max. air)


design engineersPanasonicENW49A01A3EF
29.0 x 13.5 x 2.66Marvell® 88W8782 WLAC SOC and 88MC200-93 dBm @ IEEE 802.11b DSSS 1 Mbps+18 dBm @ IEEE 802.11b-30 to +70 °CTX 430 mA @ 11b, 11Mbps and 145 mA Rx2.4 GHz65/72.2/135/150 Mbps

Features

  • Surface Mount Type 29.0 x 13.5 x 2.66 mm³
  • Fully Embedded Wi-Fi module with integrated MCU, Radio, Wi-Fi stack, antenna and crystals
  • Supports IEEE 802.11 b/g/n, security standards WEP, WPA, WPA2, WPA2 PSK
  • Tx Power up to +18 dBm (IEEE 802.11b CCK) and 14dBm (IEEE 802.11g ODFM)
  • High Rx Sensitivity -98 dBm (IEEE 802.11b DSSS 1Mbps)
  • Telnet, HTTP, AJAX and JSON Interfaces
  • Simultaneous Access point and Infrastructure modes
  • Supports TLS/SSL, https and Wi-Fi security (WPA2) for Secure Data Connections
  • Plug-n-Play Name Services (DHCP, DNS) and Custom Name Access (http://yourdevice)
  • Wireless Update of Radio Driver and MCU Firmware with Integrated Boot loader
  • Marvell® 88W8782 WAN System-on-Chip (SoC) and 88MC200 (MCU) Inside
  • Integrated, Extendable 1.5MB Flash for Web Content and Configuration File
  • Easy to use Evaluation Board for Quick Development and Reduced time to Market
  • Use of Web Technologies (HTML, JavaScript), no need for Wi-Fi Stack implementation
  • Ready to use internet access (integrated Email Server and Cloud Communication Client)
  • Getting started Tutorials, Libraries, and APIs
  • Evaluation and Development software Wifigurator for Windows

Embedded Wireless Applications

Imaging PlatformAsset Monitoring Tracking
Gaming PlatformLocation Applications
Consumer ElectronicIndustrial Controls
Portable ApplicationCommercial Monitoring
Health & FitnessMedical Devices
Smart EnergyThermostat, Control Panels

Technical Parameters

ParameterValueCondition/Note
Software Full Embedded
Rx Sensitivity-98 dBm@ 1M-DSSS (See Datasheet for Details)
Tx Power+18 dBm@ 11b
Power Supply3.0 to 3.6 V
Current Consumption430 mA, 160 mATx, Rx max @ 11b
Centre Frequency2.4GHz802.11 b/g/n
Operating Temperature Range-30 to 70C
Size29.0 x 13.5 x 2.66

Ordering Information

Part NumberDescription
ENW-49A10A3EFPAN9320 Series, Embedded Wi-Fi Module, VIPAR Stack., -30-70°C, Chip Antenna
ENW-49A10C3EFPAN9310 Series, Embedded Wi-Fi___33 Module, VIPAR Stack., -30-70°C, 50 Ohm Pad
EVAL_PAN9320EMKPAN9320 Experimenter Kit, Motherboard and Daughter Board
EVAL_PAN9320ETUPAN9320 Daughter Board

Block Diagram
