TPS Series

The TPS Series POSCAP™ Capacitors can withstand 105oC for 2,000 hours with a large capacitance of 150µF to 330µF. With its high reliability within miniature electronics applications, the TPS Series is an ideal Capacitor for usage in micro-electronic applications. The TPS Series Capacitors are ideal for various applications such as noise reduction, limited space, wearables, and more.

Features

Small Size: 3.5 x 2.8mm
Low Profile: 1.2mm Maximum Height
Endurance: 2,000 hours 105oC
Capacitance Range: 150µF to 330µF Max.
Voltage Range: 2.5 V.DC To 6.3 V.DC
Halogen Free
RoHS And REACH Compliant

Benefits

High Reliability and Long Life
Advantageous in Size Constrained PCBs

TPS Series

Part number list

Results 5

Models table for series TPS Series
Part No.	Rated Voltage (DC) (V)	Body Type	Capacitance (µF)	Polarity Type	Operating Temperature Range (°C)	Rated Voltage (V)	Endurance (h)	Permissible Ripple Current (Rms) (mA)	Tolerance on Capacitance (%)	E.S.R.-1 (Max. Value) (mΩ)	Temperature Range (°C)	Leakage Current (Max.) (μA)	Length * Width (mm)	Endurance@Temp.-1	Height (mm)	Size Code	Rated Ripple Current-1 (mArms)	Rated Ripple Current-1 (temp.) (°C)	Rated Ripple Current-1 (freq.) (kHz)	ESR (mΩ)	ESR Frequency (kHz)	Leakage Current [Max.] (μA)	Dissipation Factor [Max.]	Body Length (mm)	Body Width (mm)	Body Height (mm)	Minimum Packaging Quantity (piece)	Forming & Packaging Feature
ETPS330MUD	2.5	Surface mount type (rectangular style)	330	Polar	-55 to 105	2.5	2000	1400	-20 to 20	30	-55 to 105	82.5	3.5 * 2.8	2000h@105°C	1.1	B1S	1400	45	100	30	100	82.5	0.1	3.5	2.8	1.1	2500	Embossed carrier taping (reel packing)
ETPS220MUD	2.5	Surface mount type (rectangular style)	220	Polar	-55 to 105	2.5	2000	1400	-20 to 20	30	-55 to 105	55.0	3.5 * 2.8	2000h@105°C	1.1	B1S	1400	45	100	30	100	55	0.1	3.5	2.8	1.1	2500	Embossed carrier taping (reel packing)
6TPS150MUD	6.3	Surface mount type (rectangular style)	150	Polar	-55 to 105	6.3	2000	1400	-20 to 20	30	-55 to 105	94.5	3.5 * 2.8	2000h@105°C	1.1	B1S	1400	45	100	30	100	94.5	0.1	3.5	2.8	1.1	2500	Embossed carrier taping (reel packing)
6TPS150MZD	6.3	Surface mount type (rectangular style)	150	Polar	-55 to 105	6.3	2000	1250	-20 to 20	35	-55 to 105	94.5	3.5 * 2.8	2000h@105°C	1.1	B1S	1250	45	100	35	100	94.5	0.1	3.5	2.8	1.1	2500	Embossed carrier taping (reel packing)
4TPS220MUD	4.0	Surface mount type (rectangular style)	220	Polar	-55 to 105	4	2000	1400	-20 to 20	30	-55 to 105	88.0	3.5 * 2.8	2000h@105°C	1.1	B1S	1400	45	100	30	100	88	0.1	3.5	2.8	1.1	2500	Embossed carrier taping (reel packing)

Models table for series TPS Series
Part No.	Rated Voltage (DC) (V)	Body Type	Capacitance (µF)	Polarity Type	Operating Temperature Range (°C)	Rated Voltage (V)	Endurance (h)	Permissible Ripple Current (Rms) (mA)	Tolerance on Capacitance (%)	E.S.R.-1 (Max. Value) (mΩ)	Temperature Range (°C)	Leakage Current (Max.) (μA)	Length * Width (mm)	Endurance@Temp.-1	Height (mm)	Size Code	Rated Ripple Current-1 (mArms)	Rated Ripple Current-1 (temp.) (°C)	Rated Ripple Current-1 (freq.) (kHz)	ESR (mΩ)	ESR Frequency (kHz)	Leakage Current [Max.] (μA)	Dissipation Factor [Max.]	Body Length (mm)	Body Width (mm)	Body Height (mm)	Minimum Packaging Quantity (piece)	Forming & Packaging Feature
ETPS330MUD	2.5	Surface mount type (rectangular style)	330	Polar	-55 to 105	2.5	2000	1400	-20 to 20	30	-55 to 105	82.5	3.5 * 2.8	2000h@105°C	1.1	B1S	1400	45	100	30	100	82.5	0.1	3.5	2.8	1.1	2500	Embossed carrier taping (reel packing)
ETPS220MUD	2.5	Surface mount type (rectangular style)	220	Polar	-55 to 105	2.5	2000	1400	-20 to 20	30	-55 to 105	55.0	3.5 * 2.8	2000h@105°C	1.1	B1S	1400	45	100	30	100	55	0.1	3.5	2.8	1.1	2500	Embossed carrier taping (reel packing)
6TPS150MUD	6.3	Surface mount type (rectangular style)	150	Polar	-55 to 105	6.3	2000	1400	-20 to 20	30	-55 to 105	94.5	3.5 * 2.8	2000h@105°C	1.1	B1S	1400	45	100	30	100	94.5	0.1	3.5	2.8	1.1	2500	Embossed carrier taping (reel packing)
6TPS150MZD	6.3	Surface mount type (rectangular style)	150	Polar	-55 to 105	6.3	2000	1250	-20 to 20	35	-55 to 105	94.5	3.5 * 2.8	2000h@105°C	1.1	B1S	1250	45	100	35	100	94.5	0.1	3.5	2.8	1.1	2500	Embossed carrier taping (reel packing)
4TPS220MUD	4.0	Surface mount type (rectangular style)	220	Polar	-55 to 105	4	2000	1400	-20 to 20	30	-55 to 105	88.0	3.5 * 2.8	2000h@105°C	1.1	B1S	1400	45	100	30	100	88	0.1	3.5	2.8	1.1	2500	Embossed carrier taping (reel packing)
