Polymer Capacitors: POSCAP™ Tantalum-Polymer Capacitors

POSCAP™ Tantalum-Polymer Capacitors design engineers Panasonic
Tantalum Capacitors – POSCAP

Solid Design, High Reliability Chip Capacitors

Panasonic POSCAP Solid Electrolyte Chip Capacitors offer stable capacitance at high frequency and temperature, with low-ESR/ESL. These Capacitors utilize a sintered tantalum anode with a proprietary high-conductivity polymer cathode. Panasonic's innovative construction and processing yields one of the lowest ESR levels in Tantalum-Polymer Capacitor technology, while exhibiting excellent performance in high frequency applications. POSCAP Capacitors are available in various, compact package sizes for a small PCB footprint while offering high volumetric efficiency for capacitance. In addition, Panasonic’s POSCAP parts demonstrate high reliability and high heat resistance, making them the ideal Chip Capacitor for digital, high-frequency devices and more.

POSCAP™ Capacitors for MLCC Replacement

The entire POSCAP Tantalum-Polymer Capacitors product line serves as a suggested MLCC Alternative product.

MLCC Alternative Banner

Line Up

Body shapeSeries/TypeData SheetImageFeaturesCategory temperature range (℃)Rated voltage range (V.DC)Capacitance range (μF)Size CodeLength * Width (mm)Height (mm)RoHS (Compliance Certificate)REACH (Report of Confirmation)
Column active Filter
Close

Filter by Body shape


Surface Mount TypeTPU*Small size
*Low profile
*Face down terminal type
-55
to +85
2.5
to 10
4.7
to 150
S09
B09
2.0 x 1.25
to 3.5 x 2.8
0.9CertificateReport of Confirmation
Surface Mount TypeTPG*Small size
*Low profile
*Large cap.: 220 uF max.
-55
to +105
2.5
to 12.5
33
to 220
B1G, B15G3.5 x 2.81.1
to 1.4
CertificateReport of Confirmation
Surface Mount TypeTPSF*Super low ESR: 6 mΩ max.
*Super low ESL: 0.7 nH
*Face down terminal type
-55
to +105
2.0
to 2.5
270B2S3.5 x 2.81.9CertificateReport of Confirmation
Surface Mount TypeTPE*Low ESR
*Last digit of part numbers were lost for models over 13 digits part number.
-55
to +105
2.0
to 10
47
to 1500
B2
D15E, D2E, D3L, D4
3.5 x 2.8
to 7.3 x 4.3
1.4
to 3.8
CertificateReport of Confirmation
Surface Mount TypeTPF*Low ESR: 7 mΩ
*Large cap.: 1500 uF
-55
to +105
2.0
to 10
150
to 1000
D2E, D3L, D47.3 x 4.31.8
to 3.8
CertificateReport of Confirmation
Surface Mount TypeTQC*High voltage: 35 V.DC max.-55
to +105
16
to 35
3.9
to 150
B2
D12, D15, D2, D3L
3.5 x 2.8
to 7.3 x 4.3
1.15
to 2.8
CertificateReport of Confirmation
Surface Mount TypeTQS*High voltage: 35 V.DC max.-55
to +105
16
to 35
6.8
to 33
B1S3.5 x 2.81.1CertificateReport of Confirmation
Surface Mount TypeTPB*Standard-55
to +105
4.0
to 10
33
to 470
B2
D3L, D4
3.5 x 2.8
to 7.3 x 4.3
1.9
to 3.8
CertificateReport of Confirmation
Surface Mount TypeTPC*Low Profile: 1.1 mm-55
to +105
6.3
to 12.5
10
to 330
B1
D2
3.5 x 2.8
to 7.3 x 4.3
1.1
to 1.9
CertificateReport of Confirmation
Surface Mount TypeTH*125℃ guaranteed-55
to +125
2.5
to 10
68
to 470
D2E, D2, D3L, D47.3 x 4.31.8
to 3.8
CertificateReport of Confirmation
Surface Mount TypeTC*125℃ guaranteed-55
to +125
2.5
to 10
100
to 1000
D2E, D3L, D47.3 x 4.31.8
to 3.8
CertificateReport of Confirmation
Surface Mount TypeTA*High reliability
*If it is intended for use in automotive applications, please contact our sales team. All requests are subject to approval
-55
to +105
2.5
to 10
47
to 680
B2
D2E, D3L
3.5 x 2.8
to 7.3 x 4.3
1.8
to 2.8
CertificateReport of Confirmation
Surface Mount TypeTV*High reliability
*125℃ Guaranteed
*If it is intended for use in automotive applications, please contact our sales team. All requests are subject to approval
-55
to +125
6.3
to 10
68
to 150
D2E, D3L7.3 x 4.31.8
to 2.8
CertificateReport of Confirmation
Surface Mount TypeTPH*Small size
*Low ESR
*Face down terminal type
-55 to +105,
-55 to +85(Rated temp.+85℃)
2.5
to 10
33
to 220
A09, A143.2 x 1.60.9
to 1.4
CertificateReport of Confirmation
