Panasonic's EEF-JZ Series, Surface Mount Type, SP-CAP™ are high-temperature long life Conductive Polymer Aluminum Electrolytic Capacitors. With many features and specifications, these Capacitors are the perfect solution for your electronic needs.

The EEF-JZ Series Capacitors have a DC leakage current of I ≦ 0.1 CV (μA) 2 minutes and a capacitance tolerance of ±20 % (120 Hz / +20 ℃). With a dissipation factor (tan δ) of ≦ 0.1 (120 Hz / + 20 ℃), these Capacitors operate at a temperature range of –55 ℃ to +125 ℃.

Panasonic EEF-JZ Series Capacitors have a category temperature range of +125 ℃ 3000 hours, category voltage applied, and a rated voltage range of 2.0 V. They also have a rated capacitance range of 560 µF and a category voltage range of 1.6 V.

In addition, the EEF-JZ Series Capacitors can withstand a surge voltage (V) of Rated voltage × 1.25 (15 ℃ to 35 ℃) and have an endurance capacitance change within ±20 % of the initial value. With a dissipation factor (tan δ) of ≦ 2 times the initial limit and a DC leakage current of ≦ 3 times the initial limit, this series of Capacitors is the perfect choice for your high temperature and long-life needs. Experience the performance and reliability of Panasonic's EEF-JZ Series SP-CAP Capacitors.

Features / Benefits of EEF-JZ Series SP-CAP

•    Low ESR: 3 to 9 mΩ
•    High Temperature / Long Life: 125℃ at 3,000 hours
•    Damp Heat Specification: 85℃, 85% RH, 1,000 hours
•    Capacitance Range: 560 µF Max.
•    Ripple Current Range: 6300 to 10200 mAr.m.s
•    Product Height: 2.3mm Max.
•    Operating Temperature Range: -55 °C to +125 °C
•    RoHS Compliant
•    Halogen Free

Applications of EEF-JZ Series SP-CAP

•    5G Base Stations
•    Network Equipment & Devices
•    Servers
•    AI Servers
•    Accelerators
•    Industrial Equipment
•    Noise Reduction and Smoothing Voltage for:
•    ASIC Power Lines
•    CPU Power Lines
•    GPU Power Lines
