AYG5V1A085M1
Specifications
Item | Performance characteristics |
---|---|
Transmission Specifications | 2 channel-Uni-direction |
Receptacle/Plug | Integrated cable and plug |
Cable Length | 1000mm |
Family Name (Head of Product No.) | AYG5V |
Transmission Rate | 20 Mbps to 8 Gbps/ch |
Type | BOARD-TO-OPTICAL FIBER |
Applications | Measuring equipment, Image processing instrument, Industrial robots, Printer, Medical equipment and other high speed transmission, Noise reduction, Electrical isolation applications |
Body Length (mm) | 12.7 |
Body Height (mm) | 5.90 |
Short Width | 9.1 |
Mated Height (mm) | 6.5 |
Supply Voltage | 3.3V (Typical) |
Power Consumption | 230mW (Max.) |
Ambient Temperature | 0 ℃ to +70℃ |
Packing Quantity | 10 pieces |
Piece Type | etc. |
Short width (mm) | 9.1 |
