AYF353925 401 in stock

Specification

Specifications table for model AYF353925
ItemPerformance characteristics
Terminal Pitch (mm)0.6
Number of Pins39
Body Height (mm)0.60
Family Name (Head of Product No.)AYF3
Lock StructureBack lock
TypeFPC
ApplicationsSmartphones, Tablet PCs, Mobile devices
Contact Pitch (mm)0.3
Soldering Terminalswithout
FPC Holding Contactswithout
Contact DirectionTop contact
Body Length (mm)13.20
Recommended PC Board Pattern Width (mm)3.15
Molded Portion Material Housing: LCP resin (UL94V-0) Lever: LCP resin (UL94V-0)
Contact and Post MaterialCopper alloy
Surface Treatment Material Base: Ni plating Surface: Au plating
Rated Current0.2A/pin contact
Insulation Resistance (Min. MΩ)(Initial)1000
Dielectric Strength150V AC for 1min.
Contact Resistance (M&Omega: Max.)160
Insertion and Removal Life (Times)20
Packing QuantityEMBOSSED TAPE AND PLASTIC REEL
Packing Quantity; Inner Carton (Pcs.) 5,000 pieces (1-reel)
Packing Quantity; Outer Carton (Pcs.)10,000 pieces
