PAN B611-1x Series Evaluation Kits

The PAN B611-1C Evaluation Board (ENW89861AXKF) features a PAN B611-1x Bluetooth® Low Energy (LE) module, which is based on the Nordic Semiconductor nRF5415L single-chip controller. The PAN B611-1C module (ENW89861C01F) comes without additional flash memory and a 32 kHz crystal, and features an on-board chip antenna ("Economy"). However, the evaluation board features an 8 MB flash memory and a 32 kHz crystal that are externally mounted. You can access all the different module interfaces, such as USB, UART, NFC, and GPIOs, easily, which makes the evaluation board ideally suited for the evaluation of the module and rapid prototyping of products.

The PAN B611-1B Evaluation Board (ENW89861DXKF) features a PAN B611-1B Bluetooth® Low Energy (LE) module, which is based on the Nordic Semiconductor nRF5415L single-chip controller. The PAN B611-1B module (ENW89861F01F) comes without additional flash memory and a 32 kHz crystal, and features a bottom pad ("Economy"). However, the evaluation board features an 8 MB flash memory and a 32 kHz crystal that are externally mounted. You can access all the different module interfaces, such as USB, UART, NFC, and GPIOs, easily, which makes the evaluation board ideally suited for the evaluation of the module and rapid prototyping of products.


Reference Documents

Part Numbers

Part NumberDescriptionSeries Name
ENW89861AXKFPAN B611-1C Evaluation BoardPAN B611-1x
ENW89860CXKFPAN B611-B Evaluation BoardPAN B611-1x

Block Diagram

Features of the PAN B611-1x Series RF Modules

  • Surface Mount Type with Castellated Holes, Dimensions:10.35 mm × 9.8 mm × 1.9 mm
  • Nordic nRF54L15 featuring a 128 MHz Arm Cortex M33 processor, 1.5 MB non-volatile Memory, and 256 KB RAM
  • Bluetooth 6.0 LE including LE 2M and LE Coded PHY
  • Supports 802.15.4 - ZigBee® and Thread
  • 128-bit AES/ECB/CCM/AAR co-processor
  • Up to 32× General Purpose I/Os (GPIO) at 1.7 V to 3.6 V, which are shared by SPI, I²C, UART, PWM, ADC (up to 14-bit), NFC, QSPI
Product image for PAN B611-1x Series Evaluation Kits

PAN B611-1x Series Evaluation Kits

Resources

Filter by:
Showing 1 to 3 of 3 results
Results3

Learn About the PAN B611-1x Series RF Modules

PAN B611-1x Module Photo
More About the PAN B611-1x Series Bluetooth RF Module

The PAN B611-1 Series is a Bluetooth 6.0 Low Energy (LE) module based on the Nordic nRF54L15 single chip controller.  These new Bluetooth Low Energy Modules feature a 128 MHz Arm Cortex M33 processor with 1.5 MB non-volatile memory and 256 KB RAM.  The PANB611-1x Module has a hybrid layout with castellated holes and bottom pads
