Evaluation Kits Products

• PAN9019/9019A Evaluation Kits

  The PAN9019/PAN9019A Series modules are available in the M.2 form factor for evaluation in conjunction with host processor evaluation kits with an M.2 Key E socket. The PAN9019/PAN9019A Series requires a powerful host processor that can execute low-level WiFi and Bluetooth Drivers, as well as host high-level WiFi application software and the Bluetooth Stack.

• PAN1780 Wirepas Mesh Demo Kit

  The PAN1780 Wirepas Mesh Demo Kit is a ready-to-use Evaluation Tool based on the PAN1780 in combination with the Wirepas Mesh connectivity stack. The kit consists of four battery-powered sensor nodes and one sink which acts as a border router. The Demo Kit is intended for engineers, product designers, or any IoT enthusiast seeking high-performance ready-to-use Wirepas Sensor Nodes to set up a Wirepas Mesh network at any time and at any place in just a few steps.

• PAN1782 Evaluation Series Board
• PAN1770 Series Evaluation Boards
• PAN9028 Adapter Kit and Evaluation Kit
• PAN9520 Series Evaluation Kit
• 1x PAN1781 Series Evaluation Kit

  The 1x PAN1781 Series Evaluation Kit is packed in a small case. The board has an Arduino Footprint and allows hardware access to the module pins as well as easy stacking of separate sensor test shields. The PAN1781 Series Evaluation Kit enables quick prototyping and software testing.

• PAN1780-AT Series Evaluation Kit
• PAN1780 Series Evaluation Kit
• PAN1740A Series Evaluation Kit

  The Wireless Connectivity Evaluation kits (PAN1740A) are provided in easy-to-use USB dongle form which are intended to enable users to quickly integrate Panasonic’s NEW PAN1740A Series RF Module into their device.

• PAN1326C2 Series Evaluation Kit
• PAN4620 Series Evaluation Kit

  PAN4620 evaluation kit introduction, ESD bag.

• PAN9026 Series Evaluation Kit

  PAN9026 packaging, adapter, design/compatibility, inclusions, and features.

• PAN1740 Series Experimenter Kit

  PAN1740EMK Experiment Kit applications, kit inclusions, benefits, and features.

• PAN1740 Series Evaluation Kit

  The PAN1740 Evaluation Kit consists of two development SMD modules mounted on a carrier board in a USB stick format.

• PAN1740 Series Beacon Experimenter Kit

  The PAN1740 Beacon Kit consists of five PAN1740 Beacon ETUs, Dialog Pro Motherboard, Beacon Adapter Board and Adaptor Cable.

• PAN1720 Series Evaluation Kit (BR Stack)

  The PAN1720 Evaluation Kit is the solution for evaluating the PAN1720, CC2540 Bluetooth module with the Bluetooth Low Energy protocol stack from BlueRadios (ENW-89820A1KF) and the PAN1720 BR-Stack Evaluation Kit.

• PAN1720 Series Evaluation Kit (TI Stack)

  The PAN1720 Evaluation Kit (TI Stack) is the solution for evaluating the PAN1720 Series, CC2540 Bluetooth RF Module and the PAN1721, CC2541 Bluetooth RF Module.

• PAN9420 Series Evaluation Kit - NRFND

  PAN9420 variations, inclusions, and functionality.

• PAN1762 Series Evaluation Kit - NRFND

  The PAN1762 Evaluation Kit is an all-inclusive and comprehensive Evaluation Kit consisting of two USB dongles, and each dongle allows design engineers to develop, run, and debug code.

• PAN1761 Series Experimenter Kit - NRFND

  Pan1761 applications, Toshiba sdk, and examples.

• PAN1026A Series Evaluation Kit - NRFND

  The PAN1026A Series contains an embedded Bluetooth SIG certified stack supporting Bluetooth Basic Rate SPP profile along with a comprehensive and extended BLE GATT profiles and services.

• PAN1026A Series Experimenter Kit - NRFND

  PAN1026A availability and application.

• PAN1323, PAN1325A/PAN1315A, PAN1326/1316, PAN1327/1317 Series Evaluation Kits - NRFND

  PAN1323, PAN1325A/PAN1315A, PAN1326/PAN1316, PAN1327/PAN1317 evaluation kits compatibility, texas instrument basis, and standards.

• PAN1455 & PAN1555 Series Evaluation Kit (HDP) - NRFND

  PAN1455/1555 not recommended for new design and compatibility.

• PAN1455 & 1555 Series Evaluation Kit (SPP) - NRFND

  PAN1455/1555 not recommended for new design, compatibility, and alternatives.

• PAN9320 Series Experimenter Kit - NRFND

  PAN9320 implementation, operations, features, firmware benefits, reliability, and performance.

• PAN1026 Series Evaluation Kits - PDN
• PAN1026EMK Series Experimenter Kit - PDN

  PAN1026EMK use, supplementation, usage, and features.

• PAN1760A Series Evaluation Kit - PDN
• PAN1760 Series Experimenter Kit - PDN
