Specification

Specifications table for model EEEFK1C752SM
ItemPerformance characteristics
Body TypeSurface mount type (vertical mount style)
Polarity Type Polar
Rated Voltage (V)16
Capacitance (µF)7500
Capacitance Tolerance (%)-20 to 20
Tangent Of Loss Angle (Max.)0.28
Leakage Current (Max.) (μA)1200
Leakage Current (Max) (micro A)1200
Operating Temperature Range (°C)-55 to 105
Body Diameter (mm)18
Body Length (mm)21.5
Rated Ripple Current (Freq.) (Hz)100000
Rated Ripple Current (mA)2640
Rated Ripple Current (Unit)mArms
Impedance (Frequency) (Hz)100000
Impedance (Max. Value) (mΩ)25
Endurance (h)5000
Forming & Packaging FeatureEmbossed carrier taping (reel packing)
AppearanceSheathless (metal case)
Minimum Packaging Quantity (PCS.)75
Minimum Packaging Quantity (pieces)75
Minimum packaging quantity (piece)75
Weight (Typ.) (g)7.88
