Film Capacitors: Automotive, Industrial and Infrastructure Use

Automotive, Industrial and Infrastructure Use design engineers Panasonic

Line Up

ClassificationSeries/TypeData SheetImageApplicationShapeFeatureCategory temp. range (℃)Rated voltage (V.DC/V.AC)Capacitance range (μF)Capacitance tolerance (%)Dielectric materialRoHS (Compliance Certificate)REACH (Report of Confirmation)
Column active Filter
Close

Filter by Classification


AutomotiveECWFGxEV charging circuit DC/DC,AC/DC converter
(smoothing, PFC)
Boxed exterior
Lead wire type
・AEC-Q200 compliant
・High safety,
・High moisture resistance,
・High Thermal shock resistance
-40 to +110630 V.DC1.0
1.5
2.2
3.0
±5%(J)
±10%(K)
PPCertificateN/A
AutomotiveECQUA (For automotive)xEV charging circuit
AC/DC converter
(X2 Capacitor)
Boxed exterior
Lead wire type
・AEC-Q200 compliant
・High safety,
・High moisture resistance,
・High Thermal shock resistance
-40 to +110275 V.AC0.10 to 4.7±10%(K)
±20%(M)
PPCertificateN/A
AutomotiveECQENoise suppressor for automobileBoxed exterior
Terminal type and Covered wire type
・High temperature guarantee
・Custom design on request
-40 to +130250 V.DC0.47 to 4.720%(M)PETCertificateN/A
AutomotiveType 1xEV inverter etc.
(For smoothing)
Boxed exterior
Terminal type
・High safety (Safety function installed)
・Small size
・High current
-40 to +105450 V.DC581-5/ +10%PPN/AN/A
AutomotiveCustom Made for xEVn/axEV inverter etc.
(For smoothing, snubber, and filtering)
Boxed exterior
Terminal type
・High safety (Safety function installed)
・Small size
・High current
・Custom design on request
Custom designCustom designCustom designCustom designPPN/AN/A
Industrial, infrastructure useEZPEPower conditioner of PV and Wind
(DC filtering and DC link)
Boxed exterior
Lead wire type
・Long life
・High safety (Equipped with a safety mechanism)
-40 to +85500 V.DC
800 V.DC
1100 V.DC
1300 V.DC
10 to 11010%(K)PPCertificateReport of Confirmation
Industrial, infrastructure useEZPE [Low profile]Micro inverters of PV
(DC link)
Boxed exterior
Lead wire type
・Long life
・High safety (Safety function installed)
・High moisture resistance
-40 to +85450 V.DC
525 V.DC
575 V.DC
630 V.DC
29
66
12
10
15%PPCertificateReport of Confirmation
Industrial, infrastructure useEZPQSolar inverters
UPS
Industrial power supplies
Inverter circuit in appliances (Air Conditioners etc.)
Boxed exterior
Lead wire type
・High Safety (Self-protecting function built-in)
・Long product life, High reliability
・ Low loss, Low ESR
・Flame retardant (Case and sealing resin)
・High moisture resistance (85 °C, 85%RH)
-40 to +85250 V.AC12
22
36
±10%PPCertificateReport of Confirmation
Industrial, infrastructure useCustom Made for trainn/aInverter circuit of train
(For smoothing, snubber, and filtering)
Boxed exterior
Terminal type
・High safety (Smoothing use and filtering use are equipped with a safety mechanism)
・Small size
・High current
・Custom design on request
Custom designCustom designCustom designCustom designPPN/AN/A
Industrial, infrastructure useIndustrial use custom Maden/aInverter circuit of industrial equipment
(For smoothing, snubber, filtering, and resonance)
Boxed exterior
Terminal type
・High safety (Smoothing use and filtering use are equipped with a safety mechanism)
・Small size
・High current
・Custom design on request
Custom designCustom designCustom designCustom designPPN/AN/A
