Specification

Specifications table for model 16SEP330M
ItemPerformance characteristics
Rated Voltage (DC) (V)16
Capacitance (µF)330
E.S.R.-1 (Max. Value) (mΩ)16
Rated Ripple Current (Rms) (mA)4720
Leakage Current (Max.) (μA)792
Operating Temperature Range (°C)-55 to 105
Endurance (h)3000
Body Diameter (mm)10
Height (Max) (mm)13
Size Code F13
Weight (Typ.) (g)1.4

Stock Check

Stock check for product 16SEP330M
DistributorQuantityInventory Date
TTI Inc
United States
Tel. 1-800-225-5884
270005/30/2020
e-Sonic
Canada
Tel. 1-800-567-6642
150506/01/2020
Master Electronics
United States
Tel. 888-473-5297
150506/01/2020
Mouser Electronics
United States
Tel. 800-346-6873
147306/01/2020
Digi-Key Electronics
United States
Tel. 1-800-344-4539
90706/01/2020
Mouser Electronics
United States
Tel. 800-346-6873
51106/01/2020
e-Sonic
Canada
Tel. 1-800-567-6642
18006/01/2020
Master Electronics
United States
Tel. 888-473-5297
18006/01/2020
Newark, An Avnet Company
United States
Tel. 1-800-4-NEWARK
16606/01/2020
Arrow Electronics
United States
Tel. 1-855-326-4757
2906/02/2020
