Specification

Specifications table for model AQY282GS
ItemPerformance characteristics
PackageSOP4
Voltage TypeAC/DC
Terminal TypeSurface-mount terminal
Packing QuantityTube packing style
Load current0.8 A
Product NameGU SOP 1 Form A High Capacity
TypeGU
Contact Arrangement1 Form A
Packing quantity<br>1-tube (pcs.)100
Packing quantity<br>Outer carton (pcs.)2,000
LED Forward Current (I<sub>F</sub>)50 mA
LED Reverse Voltage (V<sub>R</sub>)5 V
Peak Forward Current (I<sub>FP</sub>)1 A
Power Dissipation (P<sub>in</sub>)75 mW
Load Voltage [ V<sub>L</sub> ] (V<sub>L</sub>)60 V
Continuous Load Current (I<sub>L</sub>)0.8 A
Peak Load Current (I<sub>peak</sub>)2.4 A
Power Dissipation (P<sub>out</sub>)300 mW
Total Power Dissipation (P<sub>t</sub>)350 mW
I/O Isolation Voltage (V<sub>iso</sub>)1,500 Vrms
Ambient Temperature: Operating (T<sub>opr</sub>)-40 to +85°C
Ambient Temperature: Storage (T<sub>stg</sub>)-40 to +100°C
Junction temperature (T<sub>j</sub>)125°C
LED Operate Current (Typical)1.1 mA
LED Operate Current (Maximum)3 mA
LED Turn Off Current (Minimum) 0.2 mA
LED Turn Off Current (Typical) 1 mA
LED Dropout Voltage (Typical) (V<sub>F</sub>)1.32 V
LED Dropout Voltage (Maximum) (V<sub>F</sub>)1.5 V
On Resistance (Typical) (R<sub>on</sub>)0.4 ohm
On Resistance (Maximum) (R<sub>on</sub>)0.8 ohm
Off State Leakage Current (Maximum) (I<sub>Leak</sub>)1μA
Over Current ProtectionNothing
Turn On Time (Typical) 1 ms
Turn On Time (Maximum) 5 ms
Turn Off Time (Typical)0.1 ms
Turn Off Time (Maximum)0.5 ms
I/O Capacitance (Maximum) (C<sub>iso</sub>)1.5 pF
Initial I/O Isolation Resistance (Minimum) (R<sub>iso</sub>)1,000 M ohm
Maximum Switching Frequency 10 cps
LED Current (I<sub>F</sub>)Min.: 5 mA, Max.: 30 mA
Load Voltage (V<sub>L</sub>)Max.: 48 V
Continuous Load Current (I<sub>L</sub>)Max.: 0.8 A
