AQ-A Series Solid State Relay

The AQ-A Series Solid State Relay is a compact size small terminal DC type Solid State Relay. It features an output-side terminal cover for safety with an input side cover available as an option. Along with LED indication, the AQ-A Series has a built-in Varistor that is excellent for surge absorption. Suggested applications for use include heating, Industrial, temperature control, and more!

Features:

High Capacity DC Switching
Compact Size (W 40 x L 58 x H 25.5mm)
Internal Diode and Terminal Cover on Output Side
Built-in Varistor
LED Indication
RoHS Compliant

Benefits:

Suitable for Usage in Solar Applications
Safe Operation
Easy Verification of Operation Status

AQ-A Series Solid State Relay

Part number list

Results 3

Models table for series AQ-A Series Solid State Relay
Part No.	Zero-Cross Function	Output Side: Max. Load Current	Output Side: Load Voltage	Type of Load	Terminal Type	Packing Quantity	Packing Quantity; Inner Carton (Pcs.)	Packing Quantity; Outer Carton (Pcs.)	Input Side: Input Voltage	Input Side: Drop-Out Voltage	Output: Non-Repetitive Surge Current	Output Side: Max. Off-State Leakage Current	Operate Time (Initial) (at 20°C)	Release Time, Max.	I/O Isolation Voltage	Ambient Temperature	Storage Temperature	Snubber Circuit	Function	Load current (A)	Load Voltage [ V_L ]	Input voltage
AQA211VL	Zero-cross	15A	75 to 250Vrms	AC type	Screw terminal	Carton	2	60	4 to 32V DC	Min. 1V	150A	10mA	1/2 cycle of voltage sine wave + 1ms	1/2 cycle of voltage sine wave + 1ms	4,000 Vrms between input and output 2,500 Vrms between input, output and case	-20°C to +80°C	-20°C to +85°C	With snubber circuit	Built-in varistor, With LED indication	15	75 to 250Vrms	4 to 32V DC
AQA411VL	Zero-cross	25A	75 to 250Vrms	AC type	Screw terminal	Carton	2	60	4 to 32V DC	Min. 1V	250A	10mA	1/2 cycle of voltage sine wave + 1ms	1/2 cycle of voltage sine wave + 1ms	4,000 Vrms between input and output 2,500 Vrms between input, output and case	-20°C to +80°C	-20°C to +85°C	With snubber circuit	Built-in varistor, With LED indication	25	75 to 250Vrms	4 to 32V DC
AQA611VL	Zero-cross	40A	75 to 250Vrms	AC type	Screw terminal	Carton	2	60	4 to 32V DC	Min. 1V	400A	10mA	1/2 cycle of voltage sine wave + 1ms	1/2 cycle of voltage sine wave + 1ms	4,000 Vrms between input and output 2,500 Vrms between input, output and case	-20°C to +80°C	-20°C to +85°C	With snubber circuit	Built-in varistor, With LED indication	40	75 to 250Vrms	4 to 32V DC
