Grid-EYE® Infrared Array Sensor

Panasonic's Grid-EYE® is an 8x8, 64 pixel Infrared Array Sensor. The Grid-EYE Sensor offers digital output (I2C) for thermal presence, direction, and temperature values. A built-in lens includes a 60-degree viewing angle and features a compact SMD design using MEMS thermopile technology.

Applications for the Grid-EYE® Sensor include human detection, people counting, thermal mapping, digital signage, security, lighting control, kiosk/ATM, medical imaging, automatic doors, robotics, and much more.

Grid-EYE® for Human Detection Applications

The Grid-EYE® Sensor can detect temperature distribution in a two-dimensional area without contact in retail stores, shopping malls, offices, and many other human detection applications. The Grid-EYE® Sensor works in tandem with software to identify the number and position of people based on their body temperature, outputting a thermal data image and recognizes where appropriate distancing or density is or isn't maintained. Learn more about how the Grid-EYE® Sensor is used in human detection applications in Panasonic's New Video!

Retail Stores

Shopping Malls

Offices

More About Grid-EYE®

FREE Thermopile Array White Paper

This White Paper, Thermopile Arrays Open Up a New World of Automation Applications, includes:

IR Sensors Introduction
Pyroelectric vs. Thermopile Arrays
What is Grid-EYE?
Grid-EYE Features and Specifications

Visit the White Paper Pagoda for this Free White Paper and many others!

Series table for lineup Grid-EYE® Infrared Array Sensor
Series/Type	Number of Pixel	Amplification Factor	RoHS (Compliance Certificate)	Operating Voltage (DC) (V)	Reach (Report of Confirmation)
Grid-EYE High performance type	64 (Vertical 8 x Horizontal 8 Matrix)	High gain, Low gain	RoHS compliant (Please refer to the Related Information.)	3.3, 5.0	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)
Grid-EYE Narrow angle type	64(Vertical 8 x Horizontal 8 Matrix)	Low gain	RoHS compliant (Please refer to the Related Information.)	5.0	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)
Grid-EYE Old type	64 (Vertical 8 x Horizontal 8 Matrix)	High gain, Low gain	RoHS compliant (Please refer to the Related Information.)	3.3, 5.0	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)

Series table for lineup Grid-EYE® Infrared Array Sensor
Series/Type	Number of Pixel	Amplification Factor	RoHS (Compliance Certificate)	Operating Voltage (DC) (V)	Reach (Report of Confirmation)
Grid-EYE High performance type	64 (Vertical 8 x Horizontal 8 Matrix)	High gain, Low gain	RoHS compliant (Please refer to the Related Information.)	3.3, 5.0	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)
Grid-EYE Narrow angle type	64(Vertical 8 x Horizontal 8 Matrix)	Low gain	RoHS compliant (Please refer to the Related Information.)	5.0	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)
Grid-EYE Old type	64 (Vertical 8 x Horizontal 8 Matrix)	High gain, Low gain	RoHS compliant (Please refer to the Related Information.)	3.3, 5.0	SVHC non-inclusion (Definition of SVHC inclusion:0.1wt% or above per product.)
