Specifications
| Item | Performance characteristics |
|---|---|
| Body Type | Surface mount type (vertical mount style) |
| Polarity Type | Polar |
| Rated Voltage (V) | 50 |
| Capacitance (µF) | 47 |
| Capacitance Tolerance (%) | -20 to 20 |
| Tangent Of Loss Angle (Max.) | 0.1 |
| Leakage Current (Max.) (μA) | 23.5 |
| Operating Temperature Range (°C) | -55 to 125 |
| Body Diameter (mm) | 8 |
| Body Length (mm) | 10.2 |
| Rated Ripple Current (Freq.) (Hz) | 100000 |
| Rated Ripple Current (mA) | 1250 |
| Rated Ripple Current (Unit) | ｍArms |
| E.S.R.-1 (Frequency) (Hz) | 100000 |
| E.S.R.-1 (Max. Value) (mΩ) | 30 |
| Endurance (h) | 4000 |
| Forming & Packaging Feature | Embossed carrier taping (reel packing) |
| Appearance | Sheathless (metal case) |
| Minimum Packaging Quantity (pieces) | 500 |
| Minimum Packaging Quantity (piece) | 500 |
| Weight (Typ.) (g) | 0.908 |
Stock check
EEHZC1H470P
