Specifications
| Item | Performance characteristics |
|---|---|
| Rated Voltage (DC) (V) | 16 |
| Capacitance (µF) | 82 |
| Body Type | Surface mount type (vertical mount style) |
| E.S.R.-1 (Max. Value) (mΩ) | 27 |
| Polarity Type | Polar |
| Rated Ripple Current (Rms) (mA) | 940 |
| Rated Voltage (V) | 16 |
| Leakage Current (Max.) (μA) | 262 |
| Operating Temperature Range (°C) | -55 to 125 |
| Tolerance on Capacitance (%) | -20 to 20 |
| Endurance (h) | 1000 |
| Temperature Range (°C) | -55 to 125 |
| Body Diameter (mm) | 5 |
| Endurance (h) | 1000 |
| Height (Max) (mm) | 6 |
| Endurance@Temp.-1 | 1000@125°C |
| Size Code | B6 |
| Weight (Typ.) (g) | 0.18 |
| Rated Ripple Current-1 (mArms) | 3000 |
| Rated Ripple Current-1 (temp.) (°C) | T≦105 |
| Forming & Packaging Feature | Embossed carrier taping (reel packing) |
| Rated Ripple Current-1 (freq.) (kHz) | 100 |
| Rated Ripple Current-2 (mArms) | 940 |
| Rated Ripple Current-2 (temp.) (°C) | 105＜T≦125 |
| Rated Ripple Current-2 (freq.) (kHz) | 100 |
| ESR (mΩ) | 27 |
| ESR Frequency (Hz) | 100 |
| ESR Frequency (kHz) | 100 |
| Leakage Current [Max.] (μA) | 262 |
| Dissipation Factor [Max.] | 0.12 |
| Body Length (mm) | 5.9 |
| Minimum Packaging Quantity (piece) | 1500 |
| Weight [Typ.] (g) | 0.18 |
Stock check
16SVF82M
