Board-to-Board Connectors

Board-to-Board Connectors

Panasonic's Board-to-Board Connectors are ideal for low profile applications. These board-to-board connectors range from 0.35mm pitch to 0.8mm pitch with various mated heights.

Features

  • High Current rating
  • Multiple High-Current Lines
  • Tough Contact Construction
  • Smooth Insertion Guide
  • Solder Terminals at Each Corner

Benefits

  • Fewer Pins Required for Power Contacts
  • Any Pin Can Be Used as a Power Contact
  • Highly Reliable Contact Structure
  • Improved Tactile Feel/Secure Connection
  • Enhanced Mounting Strength

Applications

  • Wearables
  • Handheld Testing Devices
  • Electric Gas Meters
  • Blood Pressure Monitors/Glucose Meters

Products

  • Narrow (Fine) Pitch ConnectorsPanasonic’s “tough contact” design provides customers with the reliability that is required when developing the latest computer or wearable device.
  • High Current ConnectorsOur high current connectors have a low mated height profiles, high reliability, and are manufactured with Panasonic's Touch Contact technology.
  • MIPTEC 3D Packaging TechnologyThree-dimensional injection molded circuit components use MID (Molded Interconnect Device) technology. Further advancements use proprietary surface activation technology and laser patterning. The result is a 3D circuit device with a fine circuit pattern for mounting bare chips. Custom shapes and patterns are produced on an order request basis.
