Specification

Specifications table for model R-5785(N)/R-5680(N)
ItemPerformance characteristics
Tg (DSC),200 °C
Tg (TMA), (°C)
Tg (DMA),210 °C
Td (Thermal Decomposition) (°C)400 °C
T288 (Without Cu) (min)>120 min
T288 (With Cu) (min)>120 min
CTE-Y, 14-16 ppm/°C
CTE-Y 14-16 ppm/°C
CTE-Z 42 ppm/°C
CTE α2 Z-axis: Test Method IPC-TM-650 2.4.24; Condition A (ppm/℃)280 ppm/°C
Thermal Conductivity, (W/m・K)0.40 W/m · K
Volume Resistivity (MΩ・cm)1 x 10⁹ MΩ · cm
Surface Resistivity (mΩ)1 x 10⁸ MΩ
Dielectric Constant (Dk) @ 1Ghz; Test Method IPC-TM-650; Condition C-24/23/503.4
Dielectric Constant (Dk) @ 10Ghz; Test Method IPC-TM-650; Condition C-24/23/50
Dielectric Constant (Dk) @ 12Ghz; Test Method Balanced-type Circular Disk Resonator; Condition C-24/23/503.4
Df at 1 GHz0.001
Df at 10 GHz
Df at 12 GHz0.002
Water Absorption (%)0.06%
Poisson's Ratio
Flexural Warp (MD) (GPa)19 GPa
Flexural Fill (TD) (GPa)18 GPa
Peel Strength (1 Oz. Cu) (kN/m)0.8 (Cu:H-VLP)
Flammability94V-0
