High Performance Type - ETQP*M***Y**

The highly reliable ETQ-PxMxxxYxx Series Power Choke Coils for automotive applications feature Panasonic's exclusive Metal Core Type technology allowing high heat resistance. Metal Composite Technology results in a nearly linear inductance vs. current performance. The ETQ-PxMxxxYxx Series offers a wide range of inductance values.

These parts are AEC-Q200 Compliant for automotive applications as well as other strenuous environments including exposure to high temperatures along with a high tolerance to vibration, which ensures optimal quality and reliability. Recommended applications include noise filter applications for various drive circuitry requiring high-temperature operation and peak current handling capability, Boost-Converter, and Buck-Converter DC/DC.

Features:

  • High Heat Resistance: Operation Up to 150°C Including Self-Heating
  • High-Reliability: High Vibration Resistance as Result of Newly Developed Integral Construction; Under Severe Reliability Conditions of Automotive and Other Strenuous Applications
  • High Bias Current: Excellent Inductance Stability Using
  • Ferrous Alloy Magnetic Material
  • Temp. Stability: Excellent Inductance Stability Over Broad Temp. Range
  • Low Audible (Buzz) Noise: A Gapless Structure Achieved With Metal Composite Core
  • High Efficiency: Low DC Resistance of Winding and Low Eddy-Current Loss of The Core
  • Shielded Construction
  • AEC-Q200 Compliant
  • RoHS Compliant

Benefits:

  • For Height-Restricted Designs
  • Near Linear Inductance vs. Current Performance
  • Resistance to Shock, Vibration and Minimal Buzz Noise
  • Operation in Strenuous Environments
  • AEC-Q200 Compliance Ensures Strict Quality Control Standards Are Being Enforced
AEC-Q200 Logo

An AEC-Q200 Compliant Series

Panasonic components specified as AEC-Q200 Compliant are consistently designed into automotive systems.  However, today’s Design Engineers are specifying AEC-Q200 components to meet the high-quality standards of devices beyond automotive applications.

Parts that pass the AEC tests are qualified, high-quality components that can be used in critical environments.  Therefore, there should be no need to conduct other component level tests saving both time and expense.

Current AEC-Q200 Standard documents developed by the AEC Component Technical Committee are available on the AEC website. The AEC is an organization based in the U.S. that sets qualification standards for the supply of components in the automotive electronics industry.

If your next device requires components that meet the Automotive Electronics Council (AEC) requirements for components suitable for harsh automotive environments, think Panasonic!

Download a complete list of Panasonic AEC-Q200 Compliant Component Series and specify reliably!

AEC-Q200-Anti-Vibration-Caps_Caps_414x200

Design In Anti-Vibration Capacitors From Panasonic

Panasonic expands twelve proven, Surface Mount Aluminum Electrolytic Capacitor series to include AEC-Q200 Compliant Anti-Vibration part numbers able to withstand 30G! Suitable for harsh automotive and strenuous environments, select Anti-Vibration variant parts where high capacitance current capability is demanded by the application.

Part Number List

Results 54
Models table for series High Performance Type - ETQP*M***Y**
Part No.DatasheetSize [L×W] (mm)Height (mm)Inductance (μH)DC Resistance [Typ.] (at 20℃) (mΩ)DC Resistance [Max.] (at 20℃) (mΩ)Rated Current [Typ.] (ΔT=40K, FR4, t=1.6 mm, Four-layer PWB) (A)Rated Current [Typ.] (ΔT=40K, High heat dissipation PWB) (A)Rated Current [Typ.] (ΔL=–30%) (A)Weight (Typ.) (g)AEC-Q200 compliant
6.5×6.0
4.5
3.3
16.1
17.71
6.4
8.2
13.3
0.9
AEC-Q200 compliant
6.5×6.0
4.5
47
210
231
1.8
2.2
3.8
0.9
AEC-Q200 compliant
5.5×5.0
4
22
163
179
1.9
2.3
3.1
0.6
AEC-Q200 compliant
6.5×6.0
3
0.68
6.3
6.9
9.8
12
24
0.6
AEC-Q200 compliant
8.5×8.0
5.4
22
63
70
4.1
4.8
6.9
1.9
AEC-Q200 compliant
8.5×8.0
5.4
48
125
138
2.9
3.4
5.4
1.9
AEC-Q200 compliant
10.7×10.0
5
97
208
229
2.2
2.7
3
2.9
AEC-Q200 compliant
10.7×10.0
5.4
2.5
5.3
5.9
15.1
18.1
27.2
3.1
AEC-Q200 compliant
10.9×10.0
6
1.5
3.2
3.52
19.5
23.3
32
2.9
AEC-Q200 compliant
7.5×7.0
5.4
4.7
20.4
22.5
6.3
8
13.1
1.5
AEC-Q200 compliant
