Bluetooth Mesh

Bluetooth® Mesh, or flood mesh networking, offers low power consumption based on Bluetooth Low Energy. It allows end nodes and relay nodes to pass envelopes of information through a network without knowing which nodes are present in the network. Any node which receives a message then forwards that message to a counter which keeps track of the number of times an envelope has been viewed until it reaches zero. This keeps the message from continuously passing through the network. The Bluetooth Mesh standard requires less computing power and saves on battery usage while passing information from one node to another.

Featured: Panasonic’s New Bluetooth® 5.0 Low Energy Mesh RF Module Based On The Nordic nRF52840 Single-Chip Controller

Click here to access Panasonic’s Wireless Connectivity Engineering Tools Library.

Here you’ll find advanced design in tools such as CAD files, design guides, application notes, software guides / files, demonstration software, quick-start guides, command specifications and more!

Choose the right RF Module for your application. Get started with Panasonic's Wireless Connectivity Solutions Guide!



Series List

Results 6
Series table for lineup Bluetooth Mesh
Series/TypeDatasheetSize (mm) (mm)Used ICsRx Sensitivity (dBm)Tx Power (Max.)Bluetooth Class/VersionOperating Temperature
15.6 x 8.7 x 2
nRF52840
-95 @ 1Mb/s and -103 @ 125Kb/s
8dBm configurable from -20dBm in 4dB steps
5.0
15.6 mm x 8.7 mm x 1.9 mm
-98 @ BER 10-³
-40°C to +85°C
44.5mm x 39.5mm x 11.3mm
-105 dBm Typical At 1% Packet Error Rate
-40°C to +85°C
35mm X 15mm X 3.5mm
-105 dBm Typical At 1% Packet Error Rate
-40°C To +85°C
35mm X 15mm X 3.5mm
-92 dBm Typical At 1% Packet Error Rate
-40°C To +85°C
20.0mm X 26.5mm X 3.0mm
–97dBm at 1% Packet Error Rate
-40°C To +85°C
