Electric Double Layer Capacitors (Gold): Wound Type

Wound Type design engineers Panasonic

Line Up

Body shapeSeries/TypeData SheetImageFeaturesCategory temp. range (℃)Endurance (h)Max. operating voltage (V.DC)Capacitance (F)RoHS (Compliance Certificate)REACH (Report of Confirmation)
Column active Filter
Close

Filter by Body shape


Wound TypeHZ・Miniaturized-25 to +7010002.53.3 to 10CertificateReport of Confirmation
Wound TypeHW[Recommendation] : 10F or less = Please consider HZ series.-25 to +60(+70)10002.3(2.1)22 to 70CertificateReport of Confirmation
Wound TypeHL・Low resistance
・2.7 V.DC
・Guaranteed at 65℃ 2000h
・Low temperature -40℃ guaranteed
-40 to +6520002.750, 100CertificateReport of Confirmation
