Panasonic, a world-leading Automotive Relay supplier offers product reliability and versatility with a proven track record. Designed to switch high DC current levels of 20A to 300A, Panasonic's Automotive Relays featured a sealed construction and wide operating temperatures that allow use in harsh environments. Other Automotive Relay options include plug-in and PC board terminal arrangements with pin-in-paste compatible versions. Hermetically sealed contact enclosures are also available.

Automotive Relays

Series comparison (29)

CB Series Relays

View series

Specifications

CM Series Relays

View series

Specifications

EV Series Relays (DC Contactors)

View series

Specifications

EV-A Series Relays (DC Contactors)

View series

Specifications

CP Series Relays

View series

Specifications

TB Series

View series

Specifications

TB Series Power Type

View series

Specifications

TE Series

View series

Specifications

TL Series

View series

Specifications

CJ Series Relays

View series

Specifications

CN-H Series Relays

View series

Specifications

CN-L Series Relays

View series

Specifications

CN-M Series Relays

View series

Specifications

CQ Series Relays

View series

Specifications

CT Series Relays

View series

Specifications

CT Series Relays Power Type

View series

Specifications

CW Series Relays

View series

Specifications

CA Series Relays

View series

Specifications

CP Series Relays Power Type

View series

Specifications

TA Series Relays

View series

Specifications

TC Series Relays

View series

Specifications

TG Series Relays

View series

Specifications

TH Series Relays

View series

Specifications

TJ Series Relays

View series

Specifications

TM Series Relays

View series

Specifications

EB-N Series Relays

View series

Specifications

EC-N Series Relays

View series

Specifications

EV Series Switches

View series

Specifications

CV-N Series Relays

View series

Specifications

Automotive Relays Available Through Panasonic Franchised Distributors

TB Series Automotive Relays

TB Series: ACTB2CR2A60 & ACTB3C2A52 Automotive Relays

Part numbers ACTB2CR2A60 and ACTB3C2A52 are the only Automotive Relay part numbers available for purchase in the TB Series through franchised distributors.

The ACTB2CR2A60 Automotive Relay is a PCB mount Relay with a 12 VDC coil which operates using a 12 VDC power supply system. This 1FormC high-quality general-purpose single Relay has more than 20 years of design in placement in the automobile market and is used in a wide range of applications in the automobile market around the world. It is Panasonic’s most popular in-vehicle Relay. The ACTB3C2A52 Automotive Relay is a high quality twin Relay with over 20 years of design in success in the global automobile market.

TB Series Power Type Automotive Relay

TB Series Power Type: ACTBPDR4V Automotive Relay

The ACTBPDR4V is the only part number available for purchase in the Panasonic Power Type TB Series Automotive Relays through franchised distributors.

The TB Series Power Type ACTBPDR4V part is a compact Automotive Relay with a 30A @ 14VDC switching capacity using a 1 Form A contact arrangement and mounted using PCB terminals. This Relay is designed for usage in a 12VDC power supply system. The ACTBPDR4V Relay is also pin-in paste compliant for automatic reflow soldering processes and uses a Ag alloy with Cu clad contacts which are capable of handling 70A inrush from capacitive loads.

TE Series Automotive Relay

TE Series: ACTE3CH2A05V Automotive Relay

The ACTE3CH2A05V is the only part number available for purchase in the Panasonic Automotive Relays TE Series through franchised distributors.

The TE Series ACTE3CH2A05V part is a compact Automotive Relay with a 20A @ 14VDC switching capacity and 25A maximum carry current rating. This Twin Type Relay has a 1 Form C x 2 contact arrangement and is mounted using PCB terminals and is also capable of switching a 25A @ 14 V DC motor lock load. This Relay is designed for usage within a dedicated 12VDC power supply system and features a small footprint area. The ACTE3CH2A05V was developed for controlling both the forward and reverse directions of a motor.

TL Series Automotive Relay

TL Series: ACTL3CR3V Automotive Relay

The ACTL3CR3V is the only part number available for purchase in the Panasonic Automotive Relays TL Series through franchised distributors.

The TL Series ACTL3CR3V Automotive Relay has a miniature design while still being capable of switching larger capacity loads. This Relay uses a double make 1 Form U (or 2 Form A) contact arrangement. The double-make structure allows for switching capabilities of 40A @ 14VDC (40A continuous energization with make-fixed contacts connected). The ACTL3CR3V part can be used to replace micro some ISO Terminal Type Relays and is designed for use within a dedicated 12VDC power supply system.
