PhotoMOS®

Small Package Size. Fast-Switching Speed and Low Capacitance.

Panasonic PhotoMOS® Relays are MOSFET-enabled Solid State Relays featuring low off-state leakage current and stable on-resistance over the component lifetime. Low CxR values, high optical isolation between input and output, and DC and AC / DC load ratings. MOSFET drivers available in SSOP, SOP 4-pin, and DIP 6-pin.

PhotoMOS® brand Relays from Panasonic are also sometimes referred to as:

Photo Relays
Photo Voltaic Relays
Solid State Relays
MOS-FET Relays

Use Panasonic's Parametric Search Tool to find the right PhotoMOS Relay for the application!

Download the comprehensive PhotoMOS® Part Number Selector Guide Here!

For superior quality and reliability, ask for Panasonic PhotoMOS® Relays by name!
